Prodotto:MTZ18-4VM DANFOSS REFRIGERATION Compress...

Le immagini sono solo per fini illustrativi. Si prega di fare riferimento alla scheda tecnica per i dettagli.
Riferimento: 097B16178
Produttore: DANFOSS REFRIGERATION
Descrizione:
Categorie:
Prodotto nuovo nel suo imballaggio d'origine con tutte le garanzie e certificazioni de DANFOSS REFRIGERATION
* Questo articolo potrebbe essere obsoleto. Se sei interessato chiedete noi un preventivo e ti diremo se ci sono unità disponibili. Se non ce ne sono più, un nostro tecnico cercherà un'alternativa fornibile con caratteristiche simili.
Richieda un preventivo e le indicheremo se sono ancora disponibili delle unità. Qualora non ne rimanessero, uno dei nostri tecnici cercherà un’alternativa fornibile con caratteristiche simili.
VISTI DI RECENTE
Refrigerants: R22, Compressor power supply [V]: 380-420V Y/YY -3- 50Hz PW, Oil type: BOCKlub A46, Anti-vibration pads: No, Legacy BOCK ID: 16178
| Peso lordo | 190.1 Kilogram |
| Peso netto | 174 Kilogram |
| Volume | 271.656 Liter |
| EAN | 5715162569986 |
| Digitare | HA44e |
| Gruppo di prodotti | Semi-hermetic compressors |
| Product Line | 92 |
| Nome del prodotto Descrizione | Reciprocating compressor HA |
| Peso lordo | 190.1 Kilogram |
| Peso netto | 174 Kilogram |
| Volume | 271.656 Liter |
| EAN | 5715162569986 |
| Digitare | HA44e |
| Gruppo di prodotti | Semi-hermetic compressors |
| Product Line | 92 |
| Nome del prodotto Descrizione | Reciprocating compressor HA |
| Alimentazione compressore [V] | 380-420V Y/YY -3- 50Hz PW |
| Altezza totale [mm] | 408 mm |
| Anti-vibration pads | No |
| Approvazione standard | No |
| Capacity regulator | No |
| Cilindro | 4 |
| Classe IP | IP44 |
| Colore | Blue (standard) |
| Connettore mandata- commenti | Standard |
| Connettore mandata- commenti | Soldering |
| Connettore mandata- commenti | Standard |
| Connettore mandata- commenti | Soldering |
| Contains batteries | No |
| Descrizione | Compressor HA44e/475-4 |
| Dimensioni attacco aspirazione [in] | 1 3/8 in |
| Dimensioni attacco mandata [in] | 1 1/8 in |
| Discharge connection size [mm] | 28 mm |
| Elenco sostanze candidate REACH | Lead (CAS no. 7439-92-1) 6,6'-di-tert-butyl-2,2'-methylenedi-p-cresol (CAS no. 119-47-1) |
| Family | HG/HA compressors |
| Fase | 3 |
| Frequency Hz | 50 |
| Hot gas temperature sensor | No |
| Identificazione modello | HA44e/475-4 |
| In scope of WEEE | No |
| Intermediate flange/adapter | No |
| Larghezza [mm] | 361 mm |
| Legacy BOCK ID | 16178 |
| Length (mm) | 717 |
| Max pressure (PS) - high side | 28 bar |
| Max pressure (PS) - low side | 19 bar |
| Model number | HA44e/475-4 |
| N. dossier SCIP | 2fb4c6ae-f5a0-44f0-9abf-d0c61b888840 |
| Nome prodotto dossier SCIP | HG/HA(X)44/…. - series |
| Oil differential pressure sensor | No |
| Oil pressure safety switch | No |
| Oil sump heater | No |
| Oil temperature sensor | No |
| Oil type | BOCKlub A46 |
| Protezione motore | INT69 G 115-230V AC, 50/60 Hz, IP00 |
| Refrigerante(i) | R22 |
| Step protection for CR/SU | No |
| Suction connection size [mm] | 35 mm |
| Tecnologia | Semi-hermetic air cooled |
| Thermal protection thermostat | No |
| Tipo | BOCK |
| Alimentazione compressore [V] | 380-420V Y/YY -3- 50Hz PW |
| Altezza totale [mm] | 408 mm |
| Anti-vibration pads | No |
| Approvazione standard | No |
| Capacity regulator | No |
| Cilindro | 4 |
| Classe IP | IP44 |
| Colore | Blue (standard) |
| Connettore mandata- commenti | Standard |
| Connettore mandata- commenti | Soldering |
| Connettore mandata- commenti | Standard |
| Connettore mandata- commenti | Soldering |
| Contains batteries | No |
| Descrizione | Compressor HA44e/475-4 |
| Dimensioni attacco aspirazione [in] | 1 3/8 in |
| Dimensioni attacco mandata [in] | 1 1/8 in |
| Discharge connection size [mm] | 28 mm |
| Elenco sostanze candidate REACH | Lead (CAS no. 7439-92-1) 6,6'-di-tert-butyl-2,2'-methylenedi-p-cresol (CAS no. 119-47-1) |
| Family | HG/HA compressors |
| Fase | 3 |
| Frequency Hz | 50 |
| Hot gas temperature sensor | No |
| Identificazione modello | HA44e/475-4 |
| In scope of WEEE | No |
| Intermediate flange/adapter | No |
| Larghezza [mm] | 361 mm |
| Legacy BOCK ID | 16178 |
| Length (mm) | 717 |
| Max pressure (PS) - high side | 28 bar |
| Max pressure (PS) - low side | 19 bar |
| Model number | HA44e/475-4 |
| N. dossier SCIP | 2fb4c6ae-f5a0-44f0-9abf-d0c61b888840 |
| Nome prodotto dossier SCIP | HG/HA(X)44/…. - series |
| Oil differential pressure sensor | No |
| Oil pressure safety switch | No |
| Oil sump heater | No |
| Oil temperature sensor | No |
| Oil type | BOCKlub A46 |
| Protezione motore | INT69 G 115-230V AC, 50/60 Hz, IP00 |
| Refrigerante(i) | R22 |
| Step protection for CR/SU | No |
| Suction connection size [mm] | 35 mm |
| Tecnologia | Semi-hermetic air cooled |
| Thermal protection thermostat | No |
| Tipo | BOCK |
