OMRON Y92A-48B H2C 9007B Y92A48BHARD - Imagen 1

Las imágenes son sólo a título ilustrativo. Por favor, revise la ficha técnica.

Y92A-48B H2C 9007B Y92A48BHARD OMRON Cubierta de protección rígida 48x48

Referencia: Y92A-48B

Código: H2C 9007B

Número de catálogo: Y92A48BHARD

Fabricante: OMRON

Descripción:

Cubierta de protección rígida 48x48

Categorías:

  • Relés > Accesorios para relés de conmutación
  • OMRON > Temporizadores > Accesorios Temporizadores

Producto nuevo en su embalaje original con todas las garantías y certificaciones de OMRON

  • Más Información
  • ETIM
  • PDF
  • Opiniones
Garantía, reparación y devolución.

Precio unitario: 6,82 €

Este precio es por unidad y muestra el valor neto (no incluye impuestos indirectos si son aplicables).

Calcule su precio por cantidad

CantidadPrecio

Plazo estándar: 2-3 días.

  • Estos plazos son una estimación y podrían variar una vez tramitado el pedido del artículo.

VISTOS ANTERIORMENTE

MÁS INFORMACIÓN

Características

Serie de temporizadores multifunción DIN 48 x 48 mm

Esta gama elaborada de temporizadores de estado sólido la componen un temporizador multifuncional, temporizador doble, temporizador estrella-triángulo y un temporizador de retardo a la desconexión

  • Panel frontal de 48 x 48 mm/enchufable
  • Modelos de alta/baja tensión (excepto -H y -G)
  • 0,05 s a 300 h (excepto -H y -G)
  • DPDT, 5 A a 250 Vc.a.
  • Transistor 100 mA a 30 Vc.c.

Ordering information

Output

Number of pins

Supply voltage

Time range

Operating mode

Order code

Relay DPDT

11

100 to 240 VAC/100 to 125 VDC

0.05 s to 300 h

ON-delay, flicker OFF start, flicker ON start, signal ON/OFF-delay, signal OFF-delay, interval

H3CR-A 100-240AC/100-125DC

24 to 48 VAC/12 to 48 VDC

H3CR-A 24-48AC/12-48DC

Transistor

24 to 48 VAC/12 to 48 VDC

0.05 s to 300 h

H3CR-AS 24-48AC/12-48DC

Relay DPDT

8

100 to 240 VAC/100 to 125 VDC

0.05 s to 300 h

ON-delay, flicker ON start,
interval, one-shot

H3CR-A8 100-240AC/100-125DC

24 to 48 VAC/12 to 48 VDC

H3CR-A8 24-48AC/12-48DC

Transistor

24 to 48 VAC/12 to 48 VDC

0.05 s to 300 h

H3CR-A8S 24-48AC/12-48DC

Relay SPDT

100 to 240 VAC/100 to 125 VDC

H3CR-A8E 100-240AC/100-125DC

24 to 48 VAC/VDC

H3CR-A8E 24-48AC/DC

Relay DPDT

11

100 to 240 VAC

0.05 s to 30 h

Flicker OFF start

H3CR-F 100-240AC/100-125DC

24 VAC/VDC

H3CR-F 24-48AC/12-48DC

8

100 to 240 VAC

H3CR-F8 100-240AC/100-125DC

24 VAC/VDC

H3CR-F8 24-48AC/12-48DC

11

100 to 240 VAC

0.05 s to 30 h

Flicker ON start

H3CR-FN 100-240AC/100-125DC

24 VAC/VDC

H3CR-FN 24-48AC/12-48DC

8

100 to 240 VAC

H3CR-F8N 100-240AC/100-125DC

24 VAC/VDC

H3CR-F8N 24-48AC/12-48DC

Time-limit contact and instantaneous contact

100 to 120 VAC

Star-delta

H3CR-G8EL 100-120AC

200 to 240 VAC

H3CR-G8EL 200-240AC

DPDT

8

100 to 120 VAC

0.05 to 12 s

Power OFF-delay

H3CR-H8LS 100-120AC

200 to 240 VAC

H3CR-H8LS 200-240AC

24 VAC/VDC

H3CR-H8LS 24AC/DC

100 to 120 VAC

0.05 to 12 m

H3CR-H8LM 100-120AC

200 to 240 VAC

H3CR-H8LM 200-240AC

24 VAC/VDC

H3CR-H8LM 24AC/DC

Accessories

Name/specifications

Order code

Flush-mounting adapter

Y92F-30

Protective cover

Y92A-48B

Front connecting socket

8-pin, finger-safe type, DIN-rail

P2CF-08-E

Front connecting socket

11-pin, finger-safe type, DIN-rail

P2CF-11-E

Back connecting socket

8-pin

P3G-08

11-pin

P3GA-11

Name/specifications

Order code

Time setting ring

Setting a specific time

Y92S-27

Limiting the setting range

Y92S-28

Panel cover

Light grey (5Y7/1)

Y92P-48GL

Black (N1.5)

Y92P-48GB

Specifications

Accuracy of operating time

±0.2% FS max. (±0.2% ±10 ms max. in a range of 1.2 s)

Influence of voltage

±0.2% FS max. (±0.2% ±10 ms max. in a range of 1.2 s)

Influence of temperature

±1% FS max. (±1% ±10 ms max. in a range of 1.2 s)

Ambient temperature

Operating: −10 to 55°C (with no icing),
storage: −25 to 65°C (with no icing)

Life expectancy

Mechanical

20,000,000 operations min. (under no load at 1,800 operations/h)

Electrical

100,000 operations min. (5 A at 250 VAC, resistive load at 1,800 operations/h)

Size in mm (H×W×D)

48×48×66.6 (H3CR-A, -F), 48×48×78 (H3CR-G, -H)

Setting error

±5% FS ±50 ms

Degree of protection

IP40 (panel surface)

Weight

Approx. 90 g

ETIM for 120938 Relés (EC002586)

CaracterísticaTipo de accesorio/repuesto (EF000215)
ValorTapa de cubierta
CaracterísticaAccesorio (EF013236)
ValorSí
CaracterísticaRecambio (EF013237)
ValorNo
