MSSB1806
ELDON
1
Disponible Envío el hoy
Panel posterior, 1800x600 MSSB1806
Panel posterior, 1800x600, para secciones plug-in, incluye perfiles verticales
These vertical profiles and rear cover, MSSB, form the basis for plug-in sections. This accessory is available off the shelf and is tested according to IEC 61439. The cover prevents staff from coming into contact with the busbar and the plug in system allows for the compartment to be extracted without turning off the power.
Sistemas de armarios eléctricos > Panel lateral/trasero (armario de control)
Potencia y distribución
* Producto nuevo en su embalaje original con todas las garantías y certificaciones de ELDON
Gracias por su interés en nuestros productos, esperamos que el plazo indicado sea conveniente para usted.
Durante la tramitación del pedido podrá seleccionar el tipo de envío que mejor se adapte a sus necesidades: Aéreo Express 24Hrs, Terrestre Standard 48/72Hrs, etc.
Descripción: | Rear cover plate to separate the plug-in sections from the plug-in busbars. It includes the profiles in which the rear plate is fixed, and in which the busbar holders must be fixed too. |
Material: | 3 mm reinforced ploycarbonate and 2 mm galvanised steel. |
Suministro: | 1 rear panel, 2 vertical profiles to fix the back plate and busbar supports and mounting material. |
Feature: | Vertical profiles and rear covers for plug-in systems. |
Advantage: | The standard accessory, which forms the base for plug-in sections, is available off the shelf and has been tested according to IEC 61439. The cover prevents maintainers from being able to access the busbars from the front of the enclosure. The plug-in system allows the compartment to be extracted and or replaced without turning the power off in the complete assembly. |
Benefit: | A flexible and reliable solution that ensures design, procurement and installation can be done efficiently reducing the labour time required. As the cover allows the compartment to be extracted, unnecessary downtime is avoided as the power can remain on, while certain procedures are carried out. |
Comment: | In order to mount this accessory, internal side panels (MSPS) are required. |
Título: | Tamaño: | Tipo: |
---|---|---|
MSSB1806 MSSB1806 ES_MSSB1806.pdf | 143 Kbytes | |
Descargar catálogo general |
