DABP121609GE ELDON Caja para bornas, 120x160x91, sin MP, ABS, IP66

Descripción:

Caja de ABS, libre de halógenos, apta para uso interior. Baja resistencia a rayos UV.

Material:

ABS. Cubierta transparente: policarbonato.

Junta:

Junta de poliuretano incorporada en la tapa de la caja.

Resistencia a la temperatura:

-40 °C a +60 °C.

Inflamabilidad:

UL94 HB.

Protección:

IP 66/67 IK 06 (-25°C), IK 07 (+35°C).

Acabado:

Color RAL 7035.

Suministro:

Base de la caja, tapa ciega, tornillos de la tapa de acero inoxidable, tornillos de montaje y embellecedores de poliamida.

Feature:

ABS terminal box, available in a wide range of sizes, with a high IP 66, 67 protection degree.

Advantage:

Customers can choose terminal boxes that meet their size requirements, off the shelf. The installed components inside the terminal box will be safe and secure due to the high protection degree.

Benefit:

Customers can receive terminal boxes with a short delivery time, that match their size requirements. This will also remove any extra costs due to oversizing. Component failure and unnecessary downtime is avoided as water and dust are prevented from entering the terminal box.

Comment:

The mounting plate, DMP, and DIN profiles, DR, have to be ordered separately, in order to complete the installation of the terminal box.
