EVSG-ORD 16/B 10064643 WISKA Black round cap RAL 9005, PA IP68 thread M16
EVSG-ORD 16/B
10064643
WISKA
100
Black round cap RAL 9005, PA IP68 thread M16
Stop end with mounted O-Ring, polyamide, RAL 9005, M16
Home > WISKA
Brand new product in its original packaging covered by the warranties and certifications provided by WISKA
Best sellers
▲More info
▲Features
| Material | Polyamide, fibre reinforced |
| Material sealing gasket | EPDM |
| Temp. range min | -40 °C |
| Temp. range max | 100 °C |
| Glow wire test | 650 °C |
| Protection class | IP66 / IP68 (5 bar 30 min) |
| Thread type | M |
| Ø Connection thread D | 16 |
| Lead | 1,5 |
| Length screw-in thread L | 6 mm |
| Total length TL | 9 mm |
| External diameter ED | 20 mm |
| Product Color | RAL 9005 |
| Order no. RAL 9005 | 10064643 |
| Type | EVSG-ORD 16 |
| Packing unit | 100 |
| ETIM-Classification | EC000032 |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE WISKA EN.pdf | 16 Mbytes |
|
| EVSG-ORD 16/B 10064643 EN_10064643.pdf | 230 Kbytes |
|
