EVSG 32/B 10061834 WISKA Black round cap RAL 9005, PA IP56 thread M32
EVSG 32/B
10061834
WISKA
100
Black round cap RAL 9005, PA IP56 thread M32
Stop end, polyamide, RAL 9005, M32
Home > WISKA
Brand new product in its original packaging covered by the warranties and certifications provided by WISKA
Best sellers
▲More info
▲Features
| Material | Polyamide, fibre reinforced |
| Temp. range min | -40 °C |
| Temp. range max | 100 °C |
| Glow wire test | 650 °C |
| Protection class | IP56 |
| Advice | with sealing IP66/IP68 |
| Thread type | M |
| Ø Connection thread D | 32 |
| Lead | 1,5 |
| Length screw-in thread L | 8 mm |
| Total length TL | 12 mm |
| External diameter ED | 37 mm |
| Product Color | RAL 9005 |
| Order no. RAL 9005 | 10061834 |
| Type | EVSG 32 |
| Packing unit | 100 |
| ETIM-Classification | EC000032 |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE WISKA EN.pdf | 16 Mbytes |
|
| EVSG 32/B 10061834 EN_10061834.pdf | 240 Kbytes |
|
