EVSF 63 10064673 WISKA Blind stopper "V0", light grey RAL 7035, PA IP56 thread M63
EVSF 63
10064673
WISKA
25
Blind stopper "V0", light grey RAL 7035, PA IP56 thread M63
Stop end flame-retardant, polyamide, RAL 7035, M63
Home > WISKA
Brand new product in its original packaging covered by the warranties and certifications provided by WISKA
Best sellers
▲More info
▲Features
| Material | Polyamide UL94-V0 |
| Temp. range min | -40 °C |
| Temp. range max | 100 °C |
| Glow wire test | 960 °C |
| Hazard level EN acc. 45545 | R22=HL3 / R23=HL3 / R24=HL3 |
| Protection class | IP56 |
| Advice | with sealing IP66/IP68 |
| Thread type | M |
| Ø Connection thread D | 63 |
| Lead | 1,5 |
| Length screw-in thread L | 12 mm |
| Total length TL | 17 mm |
| External diameter ED | 70 mm |
| Product Color | RAL 7035 |
| Order no. RAL 7035 | 10064673 |
| Type | EVSF 63 |
| Packing unit | 25 |
| ETIM-Classification | EC000032 |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE WISKA EN.pdf | 16 Mbytes |
|
| EVSF 63 10064673 EN_10064673.pdf | 201 Kbytes |
|
