EVSF 50 10064672 WISKA Blind plug "V0", light grey RAL 7035, PA IP56 thread M50
EVSF 50
10064672
WISKA
50
Blind plug "V0", light grey RAL 7035, PA IP56 thread M50
Stop end flame-retardant, polyamide, RAL 7035, M50
Home > WISKA
* Brand new product in its original packaging covered by the warranties and certifications provided by WISKA
Best sellers
▲More info
▲Features
| Material | Polyamide UL94-V0 |
| Temp. range min | -40 °C |
| Temp. range max | 100 °C |
| Glow wire test | 960 °C |
| Hazard level EN acc. 45545 | R22=HL3 / R23=HL3 / R24=HL3 |
| Protection class | IP56 |
| Advice | with sealing IP66/IP68 |
| Thread type | M |
| Ø Connection thread D | 50 |
| Lead | 1,5 |
| Length screw-in thread L | 10 mm |
| Total length TL | 15 mm |
| External diameter ED | 56 mm |
| Product Color | RAL 7035 |
| Order no. RAL 7035 | 10064672 |
| Type | EVSF 50 |
| Packing unit | 50 |
| ETIM-Classification | EC000032 |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE WISKA EN.pdf | 12 Mbytes |
|
| EVSF 50 10064672 EN_10064672.pdf | 201 Kbytes |
|
