EVSF 40 10064671 WISKA Blind stopper "V0", light grey RAL 7035, PA IP56 thread M40
EVSF 40
10064671
WISKA
50
Blind stopper "V0", light grey RAL 7035, PA IP56 thread M40
Stop end flame-retardant, polyamide, RAL 7035, M40
Home > WISKA
Brand new product in its original packaging covered by the warranties and certifications provided by WISKA
Best sellers
▲More info
▲Features
| Material | Polyamide UL94-V0 |
| Temp. range min | -40 °C |
| Temp. range max | 100 °C |
| Glow wire test | 960 °C |
| Hazard level EN acc. 45545 | R22=HL3 / R23=HL3 / R24=HL3 |
| Protection class | IP56 |
| Advice | with sealing IP66/IP68 |
| Thread type | M |
| Ø Connection thread D | 40 |
| Lead | 1,5 |
| Length screw-in thread L | 8 mm |
| Total length TL | 13 mm |
| External diameter ED | 46 mm |
| Product Color | RAL 7035 |
| Order no. RAL 7035 | 10064671 |
| Type | EVSF 40 |
| Packing unit | 50 |
| ETIM-Classification | EC000032 |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE WISKA EN.pdf | 16 Mbytes |
|
| EVSF 40 10064671 EN_10064671.pdf | 201 Kbytes |
|
