EVSF 12 10064666 WISKA Blind plug "V0", light grey RAL 7035, PA IP56 thread M12
EVSF 12
10064666
WISKA
100
Blind plug "V0", light grey RAL 7035, PA IP56 thread M12
Stop end flame-retardant, polyamide, RAL 7035, M12
Home > WISKA
* Brand new product in its original packaging covered by the warranties and certifications provided by WISKA
More info
▲Features
| Material | Polyamide UL94-V0 |
| Temp. range min | -40 °C |
| Temp. range max | 100 °C |
| Glow wire test | 960 °C |
| Hazard level EN acc. 45545 | R22=HL3 / R23=HL3 / R24=HL3 |
| Protection class | IP56 |
| Advice | with sealing IP66/IP68 |
| Thread type | M |
| Ø Connection thread D | 12 |
| Lead | 1,5 |
| Length screw-in thread L | 6 mm |
| Total length TL | 8 mm |
| External diameter ED | 15 mm |
| Product Color | RAL 7035 |
| Order no. RAL 7035 | 10064666 |
| Type | EVSF 12 |
| Packing unit | 100 |
| ETIM-Classification | EC000032 |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOG WISKA CABLE ENTRIES AND PROTECTION EN.pdf | 8 Mbytes |
|
| PDF CATALOG WISKA JUCTION BOXES EN.pdf | 3 Mbytes |
|
| PDF CATALOG WISKA LIGHTING INSTALLATION AND MARITIME APP EN.pdf | 5 Mbytes |
|
| EVSF 12 10064666 EN_10064666.pdf | 201 Kbytes |
|
