NEWV0303 7TCA297120R0346 THOMAS AND BETTS EX FITTING 90º PA12 ROSC LAT NIQ M16
NEWV0303
7TCA297120R0346
THOMAS AND BETTS
10
EX FITTING 90º PA12 ROSC LAT NIQ M16
EX 90 ELBOW
PMA cable protection
Brand new product in its original packaging covered by the warranties and certifications provided by THOMAS AND BETTS
Best sellers
▲More info
▲- Extended Product Type:
- NEWV0303
- Product ID:
- 7TCA297120R0346
- EAN:
- 5011949239920
- Catalog Description:
- EX 90 ELBOW
- Long Description:
- Conduit Fitting, 90 Degree Bent Elbow with External Male Thread, Conduit Size 16mm, M16 Thread, Minimum Bore 12mm, Suitable for Unbraided Nylon Conduit, Approved for Zone 1 and 2, Zone 21 and 22, IP68 Rating, Modified Nylon 12 with Nickel Plated Threads, Black
Ordering
- EAN:
- 5011949239920
Dimensions
- Product Net Weight:
- .1lb
45.351 g
Container Information
- Package Level 1 Units:
- 10 piece
- Package Level 1 Width:
- 11.9 in
302 mm
- Package Level 1 Height:
- 7.9 in
201 mm
- Package Level 1 Depth / Length:
- 8.3 in
211 mm
- Package Level 2 Units:
- 200 piece
- Package Level 2 Width:
- 15.8 in
401 mm
- Package Level 2 Height:
- 11.9 in
302 mm
- Package Level 2 Depth / Length:
- 8.3 in
211 mm
Additional Information
- Application:
- For Indoor and Outdoor Applications
- Brand / Label:
- PMA
- Color:
- Black
- Insulation Class:
- IP68
- Material:
- Modified Nylon 12 with Nickel Plated Threads
- Number of Batteries:
- 0
- Product Name:
- NYLON EX FITTING
- Product Type:
- 90 Degree Conduit Fitting with Male Thread
- Size:
- Conduit Size 16mm ; M16 Thread
- Special Functions:
- Nickel Plated Threads for Extra Stength
- Standards:
- ATEX:SEV15ATATEX0121, IECEX:IECEx SEV15.0009, Ex eb IIC, Ex tb IIIC
- Temperature Range:
- -5 to 85 °C
Certificates and Declarations (Document Number)
- Data Sheet, Technical Information:
- 9AKK106930A7763
- Declaration of Conformity - CE:
- 9AKK107680A0674
- Instructions and Manuals:
- NEWV0303
Classifications
- ETIM 6:
- EC001176 - Screw connection for corrugated plastic hose
- ETIM 7:
- EC001176 - Screw connection for corrugated plastic hose
- UNSPSC:
- 39121311
- WEEE Category:
- Product Not in WEEE Scope
- IDEA Granular Category Code (IGCC):
- 4441 >> Electrical fittings
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOG PMA CABLES PROTECTION EN.pdf | 7 Mbytes |
|
| PDF CATALOGUE THOMAS&BETTS EN.pdf | 18 Mbytes |
|
| NEWV0303 7TCA297120R0346 EN_7TCA297120R0346.pdf | 81 Kbytes |
|
