3SB2203-0AC01 SIEMENS Pushbutton, 16 mm, round, plastic, red, pushbutton, flat, 1 NC View larger
Images are for illustrative purposes only. Please refer to data sheet for details.

3SB2203-0AC01 SIEMENS Pushbutton, 16 mm, round, plastic, red, pushbutton, flat, 1 NC

3SB2203-0AC01

SIEMENS

Pushbutton, 16 mm, round, plastic, red, pushbutton, flat, 1 NC

More details


CONTROL AND CONTACTORS > Commanding and signaling devices

Brand new product in its original packaging covered by the warranties and certifications provided by SIEMENS

Total: $25.74
Unit price: $25.74
This price is per unit and is the net value (not including taxes if applicable).

If our price is not the best, please ask us for a quote. Ask for a quotation

Best sellers

▲

More info

▲


Technical data

Pushbutton, 16 mm, round, plastic, red, pushbutton, flat, 1 NC
product brand nameSIRIUS
product designationPushbuttons
design of the productComplete unit round
product type designation3SB2
Enclosure
number of command points1
Actuator
design of the actuating elementPushbutton
principle of operation of the actuating elementmomentary contact type
product extension optional light sourceNo
color of the actuating elementred
material of the actuating elementplastic
shape of the actuating elementFlat pushbutton
type of unlocking devicewithout
number of switching positions2
Front ring
product component front ringYes
design of the front ringStandard
material of the front ringplastic
color of the front ringblack
Holder
material of the holderPlastic
Contact block/ lampholder
number of lampholders0
number of switching elements1
General technical data
product function
● positive openingYes
● EMERGENCY STOP functionNo
type of voltage of the operating voltageAC/DC
protection class IPIP65
vibration resistance according to IEC 60068-2-620 ... 200 Hz: 5g
operating frequency maximum1 000 1/h
mechanical service life (switching cycles) typical10 000 000
reference code according to IEC 81346-2S
Substance Prohibitance (Date)07/01/2006
operating voltage rated value5 ... 250 V
Auxiliary circuit
number of NC contacts for auxiliary contacts1
number of NO contacts for auxiliary contacts0
number of CO contacts for auxiliary contacts0
operational current at AC-12
● at 24 V rated value10 A
● at 60 V rated value10 A
● at 110 V rated value10 A
● at 230 V rated value10 A
operational current at AC-15
● at 24 V rated value4 A
● at 110 V rated value4 A
● at 230 V rated value4 A
operational current at DC-12
● at 24 V rated value6 A
● at 60 V rated value5 A
● at 110 V rated value2.5 A
● at 230 V rated value1 A
operational current at DC-13
● at 24 V rated value3 A
● at 60 V rated value1.2 A
● at 110 V rated value0.7 A
● at 230 V rated value0.3 A
Connections/ Terminals
type of electrical connectiontab terminals
tightening torque of the screws in the bracket0.4 N·m
Ambient conditions
ambient temperature
● during operation-25 ... +70 °C
● during storage-40 ... +80 °C
environmental category during operation according to IEC 607213K6
Installation/ mounting/ dimensions
fastening methodfront plate mounting
shape of the installation openinground
mounting diameter16 mm
mounting height8 mm
installation width19 mm
installation depth50 mm
Certificates/ approvals

Downloads and manuals

General Product ApprovalDeclaration of Conformity

CSA

CCC

UL

EAC

EC/EU-Declaration of Conformity

UK Declaration of Conformity

Test Certificatesother

Special Test Certificate

Miscellaneous

Confirmation

Further information
Information- and Downloadcenter (Catalogs, Brochures,…)
Industry Mall (Online ordering system)
Cax online generator
Service&Support (Manuals, Certificates, Characteristics, FAQs,...)
Image database (product images, 2D dimension drawings, 3D models, device circuit diagrams, EPLAN macros, ...)
last modified:1/26/2022
Date
5/14/2022		Subject to change without notice
© Copyright Siemens 2022


Additional data

Product
Article Number (Market Facing Number)3SB2203-0AC01
Product DescriptionPushbutton, 16 mm, round, plastic, red, pushbutton, flat, 1 NC
Product familyComplete units
Product Lifecycle (PLM)PM300:Active Product
Price data
Region Specific PriceGroup / Headquarter Price Group41J / 41J
Surcharge for Raw MaterialsNone
Metal FactorLA------
Delivery information
Export Control RegulationsAL : N / ECCN : N
Standard lead time ex-works2 Day/Days
Net Weight (kg)0,020 Kg
Packaging Dimension50,00 x 72,00 x 50,00
Package size unit of measureMM
Quantity Unit1 Piece
Packaging Quantity1
Additional Product Information
EAN4011209028111
UPC754554630960
Commodity Code85365080
LKZ_FDB/ CatalogIDCC-IC10
Product Group5834
Group CodeR711
Country of originCzech Republic
Compliance with the substance restrictions according to RoHS directiveSince: 01.07.2006
Product classA: Standard product which is a stock item could be returned within the returns guidelines/period.
WEEE (2012/19/EU) Take-Back ObligationYes
REACH Art. 33 Duty to inform according to the current list of candidates
There is currently no information on SVHC (Substances of Very High Concern http://echa.europa.eu/web/guest/candidate-list-table) from the supply chain and our established procedures for screening our products for Substances of Very High Concern.We compare our products regularly with the information of the upstream users with regard to the substances indicated in the candidate list in accordance with the requirements of the REACH regulation. As soon as we have new findings, our information will be updated accordingly.
Classifications
VersionClassification
eClass627-37-12-28
eClass7.127-37-12-28
eClass827-37-12-28
eClass927-37-12-28
eClass9.127-37-12-28
ETIM5EC001028
ETIM6EC001028
ETIM7EC001028
ETIM8EC001028
IDEA45210
UNSPSC1439-12-22-16
UNSPSC1539-12-22-16

ETIM data

ETIM: EC001028 - Push button, complete

Value Unit
Construction type lens (EF006253) -
Degree of protection (NEMA) (EF011959) -
Number of command positions (EF001372) 1
Type of button (EF001546) Flat
Colour button (EF000190) Red
Hole diameter (EF000079) 16.0mm
Width opening (EF004565) 19.0mm
Height opening (EF004778) 8.0mm
Suitable for illumination (EF001142) false
Switching function latching (EF007447) FALSE
Spring-return (EF001407) FALSE
Number of contacts as normally open contact (EF008256) 0
Number of contacts as normally closed contact (EF008255) 1
Number of contacts as change-over contact (EF008257) 0
Type of electric connection (EF003961) Flat plug-in connection
With front ring (EF006014) true
Material front ring (EF005972) Plastic
Colour front ring (EF002429) Black
Degree of protection (IP) (EF005474) IP65
Supply voltage lamp (EF006522) -V



Datasheet - PDF

▲
Title: Size: Type:
PDF CATALOGUE SIEMENS EN.pdf 120 Mbytes
PDF CATALOGUE SIEMENS EN.pdf 104 Mbytes
3SB2203-0AC01 3SB2203-0AC01 EN_3SB2203-0AC01.pdf 198 Kbytes 3SB2203-0AC01 3SB2203-0AC01 EN_3SB2203-0AC01.pdf
