SCAME 591.SEM6302 591.SEM6302 - Image 1

Images are for illustrative purposes only. Please refer to data sheet for details.

591.SEM6302 SCAME SWITCH DISCONNECTOR 63A 2P IP66

Reference: 591.SEM6302

Manufacturer: SCAME

Description:

SWITCH DISCONNECTOR 63A 2P IP66
MANOEUVRING INT. 63A 2P IP66
63A 2P IP66 201x270x160mm II 2GD EMERGENCY YELLOW/RED

Categories:

  • Industrial socket/plug applications > Explosion proof switch
  • SCAME > Switches - SCAME

Brand new product in its original packaging covered by the warranties and certifications provided by SCAME

  • More Info
  • Reviews
Guarantee, repair and return.

Unit Price: 1.277,08 €

This price is per unit and is the net value (not including taxes if applicable).

Calculate price by quantity

QuantityPrice

Standard lead time: 20 days.

  • These delivery times are an estimate any may vary when the item order has been processed.

LAST VIEWED

MORE INFO

Commercial Series
ISOLATORS-EX[GD] Series
Synthetical description
SWITCH DISCONNECTOR
Construction type
Enclosed
Mounting version
SURFACE MOUNTING
Material
STAINLESS STEEL [AISI316L]
Protection degree IP
IP66
Type
EMERGENCY
Colour
YELLOW/RED
Rated current
63A
Poles
2P
Dimensions
201x270x160mm
Cable entry
2xM40
Cable size
ø22-32mm
Impact resistance
7J
Padlock
ø6mm
Group and categories EX
II 2GD
Ambient temperature Ta min
-35 °C
Ambient temperature Ta max
40 °C
Rated insulation voltage (Ui)
690VAC
Current (Ie) in AC22A (690V)
63A
Current (Ie) in AC23A (500V)
63A
Current (Ie) in AC23A (690V)
63A
Current (Ie) in AC3 (500V)
50A
Terminals - Flexible wires
25mm²
Terminals - Rigid wires
35mm²
Terminals tightening torque
2,5Nm
Catalogue notes
Handle padlockable in OFF (3 padlocks) and ON (1 padlock) position
Earth-stud included
ATEX [ATmosphères EXplosibles]: for applications in potentially explosive atmospheres.
