591.AEM2002 SCAME SWITCH DISCONNECTOR 20A 2P IP66

Reference: 591.AEM2002

Manufacturer: SCAME

Description:

SWITCH DISCONNECTOR 20A 2P IP66
MANOEUVRING INT. 20A 2P IP66
20A 2P IP66 202x232x142mm II 2GD EMERGENCY YELLOW/RED

Categories:

  • Industrial socket/plug applications > Explosion proof switch
  • SCAME > Switches - SCAME

Brand new product in its original packaging covered by the warranties and certifications provided by SCAME

  • More Info
  • Reviews
Guarantee, repair and return.

Unit Price: 432,77 €

This price is per unit and is the net value (not including taxes if applicable).

Calculate price by quantity

QuantityPrice

Standard lead time: 20 days.

  • These delivery times are an estimate any may vary when the item order has been processed.

LAST VIEWED

MORE INFO

Commercial Series
ISOLATORS-EX[GD] Series
Synthetical description
SWITCH DISCONNECTOR
Construction type
Enclosed
Mounting version
SURFACE MOUNTING
Material
DIE-CAST ALUMINIUM
Protection degree IP
IP66
Type
EMERGENCY
Colour
YELLOW/RED
Rated current
20A
Poles
2P
Dimensions
202x232x142mm
Cable entry
2xM25
Cable size
ø10-14mm
Impact resistance
7J
Padlock
ø6mm
Group and categories EX
II 2GD
Ambient temperature Ta min
-35 °C
Ambient temperature Ta max
60 °C
Rated insulation voltage (Ui)
690VAC
Current (Ie) in AC22A (690V)
20A
Current (Ie) in AC23A (500V)
20A
Current (Ie) in AC3 (500V)
20A
Terminals - Flexible wires
10mm²
Terminals - Rigid wires
16mm²
Terminals tightening torque
0,8Nm
Catalogue notes
Handle padlockable in OFF (3 padlocks) and ON (1 padlock) position
Earth-stud included
ATEX [ATmosphères EXplosibles]: for applications in potentially explosive atmospheres.
