590.HEMF3202 SCAME SWITCH DISCONNECTOR IP65 32A 2P View larger
Images are for illustrative purposes only. Please refer to data sheet for details.

590.HEMF3202 SCAME SWITCH DISCONNECTOR IP65 32A 2P

590.HEMF3202

SCAME

SWITCH DISCONNECTOR IP65 32A 2P

MANEUVER INT. 32A 2P IP65 EMERGENCY

32A 2P IP65 gG 10,3x38mm 217x253x93mm F1 IK08 EMERGENCY YELLOW/RED FUSE: CILINDRICO

More details


Low-voltage industrial components > Switch disconnector

Switches - SCAME

Brand new product in its original packaging covered by the warranties and certifications provided by SCAME

* This article is restricted. Please ask us for a quotation and we will check if there are units available or we will offer you an alternative product.

If our price is not the best, please ask us for a quote. Ask for a quotation

Best sellers

▲

More info

▲


Commercial Series
ISOLATORS-AL Series
Synthetical description
SWITCH DISCONNECTOR
Construction type
Enclosed
Mounting version
SURFACE MOUNTING
Material
DIE-CAST ALUMINIUM
Protection degree IP
IP65
Installation temperature
-25°C/+60°C
Type
EMERGENCY
Colour
YELLOW/RED
Rated current
32A
Poles
2P
Switch size
F1
Fuse type
gG 10,3x38mm
Rated voltage
690V
Dimensions
217x253x93mm
Notes
FUSE: CILINDRICO
Protection degree IK
IK08
Rated insulation voltage (Ui)
690VAC
400VDC
Rated impulse voltage (Uimp)
4kV
Thermal current (Ithe)
32A
Current (Ie) in AC21A (415V)
32A
Current (Ie) in AC21A (500V)
32A
Current (Ie) in AC21A (690V)
32A
Current (Ie) in AC22A (415V)
32A
Current (Ie) in AC22A (500V)
32A
Current (Ie) in AC22A (690V)
32A
Current (Ie) in AC23A (415V)
32A
Current (Ie) in AC23A (500V)
32A
Current (Ie) in AC23A (690V)
32A
Current (Ie) in AC3 (415V)
25A
Current (Ie) in AC3 (690V)
18A
Current (Ie) in DC22A (250V)
32A
Current (Ie) in DC22A (600V)
10A
Power AC23A (415V)
15kW
Short-time current
400A Icw(1s)
Conditional short circuit cur.
10kAeff
Associate fuse - type gG
32A
Terminals - Flexible wires
1.5-10mm²
Terminals - Rigid wires
1.5-16mm²
Catalogue notes
Equipped with door interlock
Fuses not supplied
Blank sides
Handle padlockable in OFF (3 padlocks) and ON (1 padlock) position


Datasheet - PDF

▲
Title: Size: Type:
PDF CATALOGUE SCAME EN .pdf 20 Mbytes
590.HEMF3202 590.HEMF3202 EN_590.HEMF3202.pdf 63 Kbytes 590.HEMF3202 590.HEMF3202 EN_590.HEMF3202.pdf
