590.HEMD8003 SCAME SWITCH DISCONNECTOR IP65 80A 3P View larger
Images are for illustrative purposes only. Please refer to data sheet for details.

590.HEMD8003 SCAME SWITCH DISCONNECTOR IP65 80A 3P

590.HEMD8003

SCAME

SWITCH DISCONNECTOR IP65 80A 3P

MANEUVER INT. 80A 3P IP65 EMERGENCY

80A 3P IP65 DIN-NH 315x410x150mm KF1 IK10 EMERGENCY YELLOW/RED FUSE: DIN-NH

More details


Low-voltage industrial components > Switch disconnector

Switches - SCAME

Brand new product in its original packaging covered by the warranties and certifications provided by SCAME

* This article is restricted. Please ask us for a quotation and we will check if there are units available or we will offer you an alternative product.

If our price is not the best, please ask us for a quote. Ask for a quotation

Best sellers

More info



Material series
ISOLATORS-AL Series
Synthetical description
SWITCH DISCONNECTOR
Material
DIE-CAST ALUMINIUM
Protection degree IP
IP65
Type
EMERGENCY
Colour
YELLOW/RED
Rated current
80A
Poles
3P
Switch size
KF1
Fuse type
DIN-NH
Rated voltage
690V
Dimensions
315x410x150mm
Notes
FUSE: DIN-NH
Protection degree IK
IK10
Catalogue notes


Datasheet - PDF
