590.HEM4006.W SCAME MANEUVER INT. 40A 6P IP66 EMERGENCY View larger
Images are for illustrative purposes only. Please refer to data sheet for details.

590.HEM4006.W SCAME MANEUVER INT. 40A 6P IP66 EMERGENCY

590.HEM4006.W

SCAME

MANEUVER INT. 40A 6P IP66 EMERGENCY

40A 6P IP65 264x315x122mm Y3 IK08 EMERGENCY YELLOW/RED HIGH WIRING CAPACITY

More details


Switches - SCAME

Brand new product in its original packaging covered by the warranties and certifications provided by SCAME

Total: $393.13
Unit price: $393.13
This price is per unit and is the net value (not including taxes if applicable).

If our price is not the best, please ask us for a quote. Ask for a quotation

Best sellers

▲

More info

▲


Commercial Series
ISOLATORS-AL Series
Synthetical description
SWITCH DISCONNECTOR
Construction type
Enclosed
Mounting version
SURFACE MOUNTING
Material
DIE-CAST ALUMINIUM
Protection degree IP
IP65
Installation temperature
-25°C/+60°C
Type
EMERGENCY
Colour
YELLOW/RED
Rated current
40A
Poles
6P
Switch size
Y3
Rated voltage
690V
Dimensions
264x315x122mm
Notes
HIGH WIRING CAPACITY
Protection degree IK
IK08
Rated insulation voltage (Ui)
690VAC
Rated impulse voltage (Uimp)
8kV
Thermal current (Ithe)
40A
Current (Ie) in AC21A (415V)
40A
Current (Ie) in AC21A (500V)
40A
Current (Ie) in AC21A (690V)
40A
Current (Ie) in AC22A (415V)
40A
Current (Ie) in AC22A (500V)
40A
Current (Ie) in AC22A (690V)
40A
Current (Ie) in AC23A (415V)
40A
Current (Ie) in AC23A (500V)
40A
Current (Ie) in AC23A (690V)
25A
Power AC23A (415V)
18.5kW
Short-time current
1,1kA Icw(1s)
Conditional short circuit cur.
50kAeff
Associate fuse - type gG
40A
Terminals - Flexible wires
2.5-16mm²
Terminals - Rigid wires
2.5-16mm²
Catalogue notes
Switch and enclosure increased dimensions
Equipped with door interlock
Handle padlockable in OFF position only (3 padlocks)
Blank sides


Datasheet - PDF

▲
Title: Size: Type:
PDF CATALOGUE SCAME EN .pdf 20 Mbytes
590.HEM4006.W 590.HEM4006.W EN_590.HEM4006.W.pdf 58 Kbytes 590.HEM4006.W 590.HEM4006.W EN_590.HEM4006.W.pdf
