590.GE8005.SN SCAME MANOEUVRING INT. 80A 3P+SN IP66/IP69 View larger
Images are for illustrative purposes only. Please refer to data sheet for details.

590.GE8005.SN SCAME MANOEUVRING INT. 80A 3P+SN IP66/IP69

590.GE8005.SN

SCAME

MANOEUVRING INT. 80A 3P+SN IP66/IP69

80A 3P+N LINK IP66/IP69 160x220x115mm Y2 IK09 GENERAL GREY/BLACK SN (WITH NEUTRAL LINK) GW 650°C

More details


Switches - SCAME > ISOLATORS Series - SCAME

Brand new product in its original packaging covered by the warranties and certifications provided by SCAME

Total: $139.37
Unit price: $139.37
This price is per unit and is the net value (not including taxes if applicable).

If our price is not the best, please ask us for a quote. Ask for a quotation

Best sellers

▲

More info

▲


Commercial Series
ISOLATORS-TP Series
Synthetical description
SWITCH DISCONNECTOR
Construction type
Enclosed
Mounting version
SURFACE MOUNTING
Material
ENGINEERING PLASTIC
Protection degree IP
IP66/IP69
Installation temperature
-25°C/+60°C
Type
GENERAL
Colour
GREY/BLACK
Rated current
80A
Poles
3P+N LINK
Switch size
Y2
Rated voltage
690V
Dimensions
160x220x115mm
Notes
SN (WITH NEUTRAL LINK)
GLOW WIRE
GW 650°C
Protection degree IK
IK09
Rated insulation voltage (Ui)
690VAC
Rated impulse voltage (Uimp)
4kV
Thermal current (Ithe)
80A
Current (Ie) in AC21A (415V)
80A
Current (Ie) in AC21A (500V)
80A
Current (Ie) in AC21A (690V)
80A
Current (Ie) in AC22A (415V)
80A
Current (Ie) in AC22A (500V)
80A
Current (Ie) in AC22A (690V)
80A
Current (Ie) in AC23A (415V)
67A
Current (Ie) in AC23A (500V)
67A
Current (Ie) in AC23A (690V)
38A
Current (Ie) in AC3 (415V)
55A
Current (Ie) in AC3 (690V)
32A
Current (Ie) in DC22A (250V)
63A
Power AC23A (415V)
37kW
Short-time current
1,5kA Icw(1s)
Conditional short circuit cur.
10kAeff
Associate fuse - type gG
80A
Terminals - Flexible wires
Terminals - Rigid wires
10-35mm²
Catalogue notes
Handle padlockable in OFF (3 padlocks) and ON (1 padlock) position
Equipped with door interlock
Blank side with drilling point marks on top side base
Break-through cable entries on bottom side base
Reversible base
Unswitched neutral (solid neutral terminal block)
