SCAME 590.F2EM12505 590.F2EM12505 - Image 1

Images are for illustrative purposes only. Please refer to data sheet for details.

590.F2EM12505 SCAME MANOEUVRING INT. 125A 3P+N IP65

Reference: 590.F2EM12505

Manufacturer: SCAME

Description:

MANOEUVRING INT. 125A 3P+N IP65
125A 3P+N IP65 264x315x122mm Y5 IK08 EMERGENCY YELLOW/RED FIRE RATED

Categories:

  • SCAME > Switches - SCAME

Brand new product in its original packaging covered by the warranties and certifications provided by SCAME

  • More Info
  • PDF
  • Reviews
Guarantee, repair and return.

* This article is restricted. Please ask us for a quotation and we will check if there are units available or we will offer you an alternative product.

Ask for a quotation and we will check if there are any units available. If not, one of our technicians will look for an alternative solution.

LAST VIEWED

MORE INFO

Commercial Series
ISOLATORS-FR Series
Synthetical description
SWITCH DISCONNECTOR
Construction type
Enclosed
Mounting version
SURFACE MOUNTING
Material
DIE-CAST ALUMINIUM
Protection degree IP
IP65
Installation temperature
-25°C/+60°C
Type
EMERGENCY
Colour
YELLOW/RED
Rated current
125A
Poles
3P+N
Switch size
Y5
Rated voltage
690V
Dimensions
264x315x122mm
Notes
FIRE RATED
Fire rated class
F200 (120min)
Protection degree IK
IK08
Rated insulation voltage (Ui)
690VAC
Rated impulse voltage (Uimp)
8kV
Thermal current (Ithe)
160A
Current (Ie) in AC21A (415V)
160A
Current (Ie) in AC21A (500V)
160A
Current (Ie) in AC21A (690V)
160A
Current (Ie) in AC22A (415V)
125A
Current (Ie) in AC22A (500V)
125A
Current (Ie) in AC22A (690V)
125A
Current (Ie) in AC23A (415V)
125A
Current (Ie) in AC23A (500V)
125A
Current (Ie) in AC23A (690V)
125A
Power AC23A (415V)
55kW
Short-time current
3kA Icw(1s)
Conditional short circuit cur.
50kAeff
Associate fuse - type gG
125A
Terminals - Flexible wires
10-70mm²
Terminals - Rigid wires
10-70mm²
Catalogue notes
Handle padlockable in OFF (3 padlocks) and ON (1 padlock) position
Equipped with door interlock
Blank sides
With late break and early make neutral pole
