590.EMF1602 SCAME SWITCH DISCONNECTOR IP65 16A 2P View larger
Images are for illustrative purposes only. Please refer to data sheet for details.

590.EMF1602 SCAME SWITCH DISCONNECTOR IP65 16A 2P

590.EMF1602

SCAME

SWITCH DISCONNECTOR IP65 16A 2P

MANEUVER INT. 16A 2P IP55 EMERGENCY

16A 2P IP55 gG 10,3x38mm 190x240x125mm F1 IK09 EMERGENCY YELLOW/RED FUSE: CILINDRICO GW 650°C

More details


Low-voltage industrial components > Switch disconnector

Switches - SCAME > ISOLATORS Series - SCAME

Brand new product in its original packaging covered by the warranties and certifications provided by SCAME

Total: $86.75
Unit price: $86.75
This price is per unit and is the net value (not including taxes if applicable).

If our price is not the best, please ask us for a quote. Ask for a quotation

Best sellers

▲

More info

▲


Commercial Series
ISOLATORS-TP Series
Synthetical description
SWITCH DISCONNECTOR
Construction type
Enclosed
Mounting version
SURFACE MOUNTING
Material
ENGINEERING PLASTIC
Protection degree IP
IP55
Installation temperature
-25°C/+60°C
Type
EMERGENCY
Colour
YELLOW/RED
Rated current
16A
Poles
2P
Switch size
F1
Fuse type
gG 10,3x38mm
Rated voltage
690V
Dimensions
190x240x125mm
Notes
FUSE: CILINDRICO
GLOW WIRE
GW 650°C
Protection degree IK
IK09
Rated insulation voltage (Ui)
400VDC
690VAC
Rated impulse voltage (Uimp)
4kV
Thermal current (Ithe)
16A
Current (Ie) in AC21A (415V)
16A
Current (Ie) in AC21A (500V)
16A
Current (Ie) in AC21A (690V)
16A
Current (Ie) in AC22A (415V)
16A
Current (Ie) in AC22A (500V)
16A
Current (Ie) in AC22A (690V)
16A
Current (Ie) in AC23A (415V)
16A
Current (Ie) in AC23A (500V)
16A
Current (Ie) in AC23A (690V)
16A
Current (Ie) in AC3 (415V)
18A
Power AC23A (415V)
7.5kW
Short-time current
400A Icw(1s)
Conditional short circuit cur.
10kAeff
Associate fuse - type gG
16A
Terminals - Flexible wires
1.5-10mm²
Terminals - Rigid wires
1.5-16mm²
Catalogue notes
Equipped with door interlock
Fuses not supplied
Blank sides
Handle padlockable in OFF (3 padlocks) and ON (1 padlock) position
