590.EMD8005 SCAME SWITCH DISCONNECTOR IP65 80A 3P+N View larger
Images are for illustrative purposes only. Please refer to data sheet for details.

590.EMD8005 SCAME SWITCH DISCONNECTOR IP65 80A 3P+N

590.EMD8005

SCAME

SWITCH DISCONNECTOR IP65 80A 3P+N

MANOEUVRING INT. 80A 3P+N IP55

80A 3P+N IP55 DIN-NH 300x380x170mm KF1 IK09 EMERGENCY YELLOW/RED FUSE: DIN-NH GW 650°C

More details


Low-voltage industrial components > Switch disconnector

Switches - SCAME > ISOLATORS Series - SCAME

Brand new product in its original packaging covered by the warranties and certifications provided by SCAME

* This article is restricted. Please ask us for a quotation and we will check if there are units available or we will offer you an alternative product.

If our price is not the best, please ask us for a quote. Ask for a quotation

Best sellers

▲

More info

▲


Commercial Series
ISOLATORS-TP Series
Synthetical description
SWITCH DISCONNECTOR
Construction type
Enclosed
Mounting version
SURFACE MOUNTING
Material
ENGINEERING PLASTIC
Protection degree IP
IP55
Installation temperature
-25°C/+60°C
Type
EMERGENCY
Colour
YELLOW/RED
Rated current
80A
Poles
3P+N
Switch size
KF1
Fuse type
DIN-NH
Rated voltage
690V
Dimensions
300x380x170mm
Notes
FUSE: DIN-NH
GLOW WIRE
GW 650°C
Protection degree IK
IK09
Rated insulation voltage (Ui)
1000VAC
1500VDC
Rated impulse voltage (Uimp)
8kV
Thermal current (Ithe)
80A
Current (Ie) in AC21A (415V)
80A
Current (Ie) in AC21A (500V)
80A
Current (Ie) in AC21A (690V)
80A
Current (Ie) in AC22A (415V)
80A
Current (Ie) in AC22A (500V)
80A
Current (Ie) in AC22A (690V)
80A
Current (Ie) in AC23A (415V)
80A
Current (Ie) in AC23A (500V)
63A
Current (Ie) in AC23A (690V)
45A
Current (Ie) in DC21A (220V)
80A
Current (Ie) in DC22A (220V)
80A
Current (Ie) in DC23A (220V)
50A
Conditional short circuit cur.
100kAeff
Associate fuse - type gG
80A
Terminal bolt size
M6
Palm width
15mm
Catalogue notes
Handle padlockable in OFF position only (3 padlocks)
Equipped with door interlock
Fuses not supplied
Blank sides
With late break and early make neutral pole
