SCAME 590.EM4015.SN 590.EM4015.SN - Image 1

Images are for illustrative purposes only. Please refer to data sheet for details.

590.EM4015.SN SCAME MANOEUVRING INT. 40A 3P+SN IP66/IP69

Reference: 590.EM4015.SN

Manufacturer: SCAME

Description:

MANOEUVRING INT. 40A 3P+SN IP66/IP69
40A 3P+N LINK IP66/IP69 110x150x87mm Y1 IK09 EMERGENCY YELLOW/RED SN (WITH NEUTRAL LINK) GW 650°C

Categories:

  • SCAME > Switches - SCAME > ISOLATORS Series - SCAME

Brand new product in its original packaging covered by the warranties and certifications provided by SCAME

  • More Info
  • PDF
  • Reviews
Guarantee, repair and return.

* This article is restricted. Please ask us for a quotation and we will check if there are units available or we will offer you an alternative product.

Ask for a quotation and we will check if there are any units available. If not, one of our technicians will look for an alternative solution.

MORE INFO

Commercial Series
ISOLATORS-TP Series
Synthetical description
SWITCH DISCONNECTOR
Construction type
Enclosed
Mounting version
SURFACE MOUNTING
Material
ENGINEERING PLASTIC
Protection degree IP
IP66/IP69
Installation temperature
-25°C/+60°C
Type
EMERGENCY
Colour
YELLOW/RED
Rated current
40A
Poles
3P+N LINK
Switch size
Y1
Rated voltage
690V
Dimensions
110x150x87mm
Notes
SN (WITH NEUTRAL LINK)
GLOW WIRE
GW 650°C
Protection degree IK
IK09
Rated insulation voltage (Ui)
690VAC
Rated impulse voltage (Uimp)
4kV
Thermal current (Ithe)
40A
Current (Ie) in AC21A (415V)
40A
Current (Ie) in AC21A (500V)
32A
Current (Ie) in AC21A (690V)
32A
Current (Ie) in AC22A (415V)
40A
Current (Ie) in AC22A (500V)
32A
Current (Ie) in AC22A (690V)
32A
Current (Ie) in AC23A (415V)
35A
Current (Ie) in AC23A (500V)
25A
Current (Ie) in AC23A (690V)
25A
Current (Ie) in AC3 (415V)
28.5A
Current (Ie) in AC3 (690V)
20A
Current (Ie) in DC22A (250V)
32A
Current (Ie) in DC22A (600V)
10A
Power AC23A (415V)
18.5kW
Short-time current
400A Icw(1s)
Conditional short circuit cur.
10kAeff
Associate fuse - type gG
40A
Terminals - Flexible wires
1.5-10mm²
Terminals - Rigid wires
1.5-16mm²
Catalogue notes
Handle padlockable in OFF position only (3 padlocks)
Equipped with door interlock
Blank side with drilling point marks on top side base
Break-through cable entries on bottom side base
Reversible base
Unswitched neutral (solid neutral terminal block)
