TC-06P1N8A80EQX 1244690 PHOENIX CONTACT Cable connector, No. of poles: 6, Direction of rotation: Standard, c..
TC-06P1N8A80EQX
1244690
PHOENIX_CONTACT
20
Cable connector, No. of poles: 6, Direction of rotation: Standard, contact connection type: Male, Crimp connection, cable diameter range: 3 mm ... 10.5 mm, coding: N, The item does not contain lead according to the RoHS II directive without exception 6c (Pb<.; 0.1%)
Cable connector
Sleeve housing for cable connector, Item is lead-free in accordance with RoHS II without Exemption 6c (Pb <0.1%)
Home > PHOENIX CONTACT
Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
Best sellers
▲More info
▲| General | Order crimp contacts Ø 2 mm separately |
| Product type | Sleeve housings |
| Insulating body | |
| Note | Order information: Order crimp contacts Ø 2 mm separately |
| Coding | N |
| Connection method | Crimp connection |
| Contact switching type | Pin |
| Application | Signal |
| Number of positions | 6 |
| Direction of rotation | Standard |
| Connection profile | 6 |
| Contact diameterPower contacts | 2 mm |
| Rated currentPower contacts | 20 A |
| Rated voltage | 48 V AC |
| 74 V DC | |
| Rated surge voltage | 1.5 kV |
| Overvoltage category | III |
| Degree of pollution | 3 |
| Seal | |
| External cable diameter | 3 mm ... 10.5 mm |
| Seal material | NBR |
