PHOENIX CONTACT  BCP-500-2 GN BDWHS1SOVPE500 5430248 - Image 1

Images are for illustrative purposes only. Please refer to data sheet for details.

BCP-500- 2 GN BDWHS1SOVPE500 5430248 PHOENIX CONTACT PCB connector

Reference: BCP-500-2 GN BDWHS1SOVPE500

Code: 5430248

Manufacturer: PHOENIX CONTACT

Product on demand only, returns will not be accepted.

Description:

PCB connector
Connector for printed circuit board, nominal cross-section: 2.5 mm², color: off-white green, nominal current: 12 A, nominal voltage (III/2): 320 V, contact surface: Tin, contact type: Female, number of potentials: 2, number of rows: 1, number of poles: 2, number of connections: 2, article family: BCP, pitch: 5 mm, connection type: Screw connection with traction capsule, connection direction conductor/printed circuit board: 0 °, clamping hook: - Clamping hook, plug-in system: BASICLINE 2.5, locking: without, fixing type: without, packaging type: packed in box
Printed circuit board connector, nominal section: 2.5 mm2, color: whitish green, nominal current: 12 A, nominal voltage (III/2): 320 V, contact surface: Sn, contact connection type: Female, number of potentials: 2, number of rows: 1, number of poles: 2, number of connections: 2, article family: BCP, pitch: 5 mm, connection type: Screw connection with traction capsule, screw clamping form: H1L Philipps-Recess with longitudinal groove, conductor connection direction/printed circuit board: 0 °, clamping hook: - Clamping hook, plug-in system: BASICLINE 2.5, locking: without, fixing type: without, packaging type: packed in box

Categories:

  • Connectors > Cable connector
  • PHOENIX CONTACT > PCB Connectors (PCC)

Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX CONTACT

  • More Info
  • ETIM
  • Reviews
Guarantee, repair and return.

Total: 866,70 €

Unit Price: 1,7334 €

This price is per unit and is the net value (not including taxes if applicable).

Calculate price by quantity

QuantityPrice

Standard lead time: 4-5 weeks.

  • These delivery times are an estimate any may vary when the item order has been processed.

LAST VIEWED

MORE INFO

Data commercial

Key orderFive million four hundred thirty thousand two hundred forty eight
Packing unit500 pcs
Key sellingAAYBAA -
Minimum order quantity500 pcs
EANFour trillion fifty five billion six hundred twenty six million three hundred thirty seven thousand two hundred seventy two
Unit weight (excluding packaging)3,160 g
Tariff number tariffEighty five million three hundred sixty six thousand nine hundred ninety
Country of originCN (China)

Environmental Product Compliance

REACh SVHCLead 7439-92-1
China RoHSSpace of time for the intended use (FEUP): 50 years
You will find information about hazardous substances in the manufacturer's declaration in the "Downloads"tab
Back to top

Ratings

eCl@ss

eCl@ss 4.0Twenty seven million two hundred sixty thousand seven hundred
eCl@ss 4.1Twenty seven million two hundred sixty thousand seven hundred
eCl@ss 5.0Twenty seven million two hundred sixty thousand seven hundred
eCl@ss 5.1Twenty seven million two hundred sixty thousand seven hundred
eCl@ss 6.0Twenty seven million two hundred sixty thousand seven hundred
eCl@ss 7.0Twenty seven million four hundred forty thousand three hundred nine
eCl@ss 8.0Twenty seven million four hundred forty thousand three hundred nine
eCl@ss 9.0Twenty seven million four hundred forty thousand three hundred nine
Back to top

ETIM

ETIM 5.0EC002638
ETIM 6.0EC002638
ETIM 7.0EC002638
Back to top

ETIM for 5430248 Connectors (EC002638)

Feature nameType of connection (EF000064)
Feature valueOther
Feature nameContact type (EF001587)
Feature valueBus
Feature nameNumber of poles (EF001391)
Feature value2
Feature nameNumber of plug-in contact rows (EF006935)
Feature value1
Feature nameModular spacing contacts (EF007326)
Feature value5 mm
Feature nameModular spacing connections (EF006827)
Feature value5 mm
Feature nameAngle contact/conductor connection (EF007546)
Feature valueOther
Feature nameRated current In (EF008250)
Feature value12 A
Feature nameRated voltage (EF000228)
Feature value320 V
Feature nameRated surge voltage (EF002993)
Feature value4 kV
Feature nameOver voltage category (EF006785)
Feature valueIII
Feature namePollution degree (EF006786)
Feature value2
Feature nameConnectable conductor cross section fine-strand without cable end sleeve (EF007341)
Feature value0.2 mm²
Feature nameConnectable conductor cross section fine-strand with cable end sleeve (EF007339)
Feature value0.25 mm²
Feature nameConnectable conductor cross section solid-core (EF007337)
Feature value0.2 mm²
Feature nameType of electric connection (EF003961)
Feature valueScrew connection
Feature nameConnectable cable type (EF006816)
Feature valueTubular cable
Feature nameMaterial of contact surface (EF004020)
Feature valueTin
Feature nameMaterial contact (EF007544)
Feature valueCopper
Feature nameMaterial insulation body (EF007543)
Feature valuePolyamide (PA)
Feature nameHousing material (EF001596)
Feature valueOther
Feature nameHousing colour (EF000136)
Feature valueOther
Feature nameInflammability class of insulation material according to UL94 (EF002521)
Feature valueV0
Feature nameOperating temperature (EF002393)
Feature value-40 °C

DATASHEET - PDF
