BCH-508VS-3 GN PA1,3 5430394 PHOENIX CONTACT Feed-through header
BCH-508VS-3 GN PA1,3
5430394
PHOENIX_CONTACT
100
Feed-through header
Printed circuit board base housing, nominal section: 2.5 mm², color: whitish green, nominal current: 12 A, dimensioning voltage (III/2): 320 V, contact surface: Tin, contact type: Male, Number of potentials: 3, Number of rows: 1, Number of poles per row: 3, number of connections: 3, family of articles: BCH-VS, pitch: 5.08 mm, Mounting: Wave Welding, Stecksystem: BASICLINE 2.5, Locking: without, Packaging Type: Boxed Packed
Connectors > Printed circuit board connector
PCB Connectors (PCC)
Brand new product in its original packaging covered by the warranties and certifications provided by PHOENIX_CONTACT
Best sellers
▲More info
▲PCB headers, nominal current: 12 A, rated voltage (III/2): 320 V, number of positions: 3, pitch: 5.08 mm, color: pastel green, contact surface: Tin, mounting: Wave soldering
Key Commercial Data
| Orderkey | 5430394 |
|---|---|
| Packing unit | 100 pc |
| Minimum order quantity | 100 pc |
| Note | Made to Order (non-returnable) |
| GTIN | 4055626366784 |
| Weight per Piece (excluding packing) | 1.090 g |
| Custom tariff number | 85366930 |
| Country of origin | CN (China) |
Environmental Product Compliance
| China RoHS | Environmentally friendly use period: unlimited = EFUP-e |
|---|---|
| No hazardous substances above threshold values |
Classifications
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOG PHOENIX PCB CONNECTORS EN.pdf | 27 Mbytes |
|
