UDP002 DP-002 PANASONIC Pressure sensor, 0 to 10bar, NPN, pressure connector M5 female thread, connector, in..
UDP002
DP-002
PANASONIC
Pressure sensor, 0 to 10bar, NPN, pressure connector M5 female thread, connector, incl. cable 2m (CN14AC2)
DP-0 pressure sensor, 0 to +10bar, NPN output, M5 female thread, connector, includes 2m connection cable with connector (CN-14A-C2)
DP-002_Digital Pressure Sensor_Digital Pressure Sensor [For Gas] DP-0_For gas
Pressure sensors - PANASONIC > DP100 dual display pressure sensor - PANASONIC
Brand new product in its original packaging covered by the warranties and certifications provided by PANASONIC
Best sellers
▲More info
▲| Product Number | DP-002 |
| Part Number | DP-002 |
| Product | Digital Pressure Sensor |
| Details | For gas |
| Product name | Digital Pressure Sensor [For Gas] DP-0 |
| Item | Specifications |
|---|---|
| Product Number | DP-002 |
| Part Number | DP-002 |
| Applicable regulations | CE Marking (EMC Directive, RoHS Directive), UKCA Marking (EMC Regulations, RoHS Regulations) |
| Type of pressure | Gauge pressure |
| Rated pressure range | 0.000 to +1.000 Mpa |
| Set pressure range | -0.010 to +1.010 MPa -0.1 to +10.30 kgf/cm2 -0.1 to + 10.10 bar -0.1 to +146.5 psi |
| Pressure withstandability | 1.5 MPa |
| Applicable fluid | Air, non-corrosive gas |
| Selectable units | MPa, kgf/cm2, bar, psi |
| Supply voltage | 12 to 24 V DC ±10 % Ripple P-P 10 % or less |
| Power consumption | 30 mA or less |
| Comparative output | NPN open-collector transistor - Maximum sink current: 50 mA - Applied voltage: 30 V DC or less (between comparative output and 0 V) - Residual voltage: 2 V or less (at 50 mA sink current) |
| Comparative output : Output operation | Selectable either NO or NC by key operation |
| Comparative output : Hysteresis | Minimum 2 digits (variable) |
| Comparative output : Repeatability | ±0.4 % F.S. (within ±4 digits) |
| Comparative output : Response time | 2.5 ms, 25 ms, 250 ms, selectable by key operation |
| Comparative output : Short-circuit protection | Incorporated |
| Display | 3 + 1/2 digits, 3-color (white / red / pink) LCD display (Display update period: 250 ms) |
| Display : Displayable pressure range | -0.010 to +1.010 MPa -0.1 to +10.30 kgf/cm2 -0.1 to + 10.10 bar -0.1 to +146.5 psi |
| Protection | IP40 (IEC) |
| Ambient temperature | 0 to +50 ℃ +32 to +122 ℉ (No dew condensation allowed), Storage: -10 to +60 ℃ +14 to +140 ℉ |
| Ambient humidity | 35 to 85 % RH, Storage: 35 to 85 % RH |
| Voltage withstandability | 500 V AC for one min. between all supply terminals connected together and enclosure |
| Insulation resistance | 50 MΩ or more with 500 V DC megger between all supply terminals connected together and enclosure |
| Vibration resistance | 10 to 150 Hz frequency, 0.75 mm double amplitude 0.030 in or maximum acceleration 49 m/s2, in X, Y and Z directions for two hours each |
| Shock resistance | 100 m/s2 acceleration (10 G approx.) in X, Y and Z directions three times each |
| Pollution degree | 2 |
| Overvoltage category | I |
| Usable altitude | 2,000 m 6,562 ft or less |
| Temperature characteristics(+20℃ standard) | +10 to +40℃ +50 to +104 ℉: Within ±2 % F.S. 0 to +50℃ 32 to +122℉: Within ±5 % F.S. |
| Grounding method | Floating |
| Pressure port | M5 female thread |
| Material | Enclosure: PBT (glass fiber reinforced) LCD display: Acrylic Pressure port: Brass (nickel plated) Mounting threaded part: Brass O-ring: Nitrile rubber (NBR) Key section: Polycarbonate |
| Weight | 25 g approx. |
| Accessories | CN-14A-C2 (Connector attached cable 2 m 6.562 ft) : 1 pc. |
| Remark | Where measurement conditions have not been specified precisely, the conditions used were an ambient temperature of +20 ℃ +68 ℉. |
