> OMRON>Advanced sensors>Other Sensors>ZN-PDA12 2M ZN 3003H ZNPDA122M OMRON Amplifier for ZN-PD03 (power sensor)
Previous Product Next Product
ZN-PDA12 2M ZN 3003H ZNPDA122M OMRON Amplifier for ZN-PD03 (power sensor) View larger
Images are for illustrative purposes only. Please refer to data sheet for details.

ZN-PDA12 2M ZN 3003H ZNPDA122M OMRON Amplifier for ZN-PD03 (power sensor)

ZN-PDA12 2M

ZN 3003H

ZNPDA122M

OMRON

Amplifier for ZN-PD03 (power sensor)

Amplifier for ZN-PD03 (sensor power)

More details


Advanced sensors > Other Advanced Sensors

Brand new product in its original packaging covered by the warranties and certifications provided by OMRON

* This article may be obsolete. Ask for a quotation and we will check if there are any units available. If not, one of our technicians will look for an alternative solution.

If our price is not the best, please ask us for a quote. Ask for a quotation

Best sellers

▲

More info

▲


Features

Monitor energy flow with a plug-and-play device

The Power Sensor Station collects and displays energy flows from multiple sources across your entire site with simple plug-and-play integration. Visualize energy data with the built-in LCD display or connect your PC with the available software for a closer look. Identify energy waste faster and simpler with the ZN Series of Power Sensor Stations.

  • Up to 31 KM50 Power Monitoring Devices can be connected in RS-485 communication or by using wi-fi converter
  • Multiple ZN can be integrated in an existing LAN network
  • SD card can be used to stored the monitoring data of the ZN
  • Graphs and monitored data can be easily represented on your PC through our Energy Viewer software
  • Monitoring data can be exported in .csv form

Ordering information

Appearance

Product name

Power supply

Order code

Station unit

DC cable

ZN-KMX21-A

Specifications

Item

ZN-KMX21-A

Connectable power sensor/monitor

KM50-E

Max. number of connectable
power sensor/monitor units

31 units

Recording interval

1 s, 2 s, 5 s, 10 s, 20 s, 30 s, 1 min.

Recorded data

Power, integrated power, power factor, sum of pulse input counts 1 and 2

Operation function

Integrated power total sum, integrated momentary power, electricity rate total sum

Memory capacity (Internal)

Internal memory: approx. 200 data items (at maximum load); approx. 6800 data items (at minimum load)

Memory capacity (External)

SD card with SDHC compatibility (Save measured values, save and read setting values)

Power supply

DC input: 24 VDC±10%

Current consumption

80 mA max.

Mounting

Magnet mounting, screw mounting, hook, free standing

Weight (when packaged)

Approx. 500 g

Dimensions


Datasheet - PDF

▲
Title: Size: Type:
PDF CATALOGO OMRON AUTOMATION EN.pdf 19 Mbytes
PDF CATALOG OMRON 2024 EN.pdf 25 Mbytes
ZN-PDA12 2M ZNPDA122M ZN 3003H zn_kmx21_users_manual_en.pdf 2 Mbytes ZN-PDA12 2M ZNPDA122M ZN 3003H zn_kmx21_users_manual_en.pdf
