SRT2-ID08CL-1 SRT27038D 338283 OMRON Module 8 PNP Inputs IP67 Compobus/S View larger
Images are for illustrative purposes only. Please refer to data sheet for details.

SRT2-ID08CL-1 SRT27038D 338283 OMRON Module 8 PNP Inputs IP67 Compobus/S

SRT2-ID08CL-1

SRT27038D

SRT2ID08CL1.1

OMRON

Available Ship on today

Module 8 Inputs PNP IP67 Compobus/S

Module 8 PNP Inputs IP67 Compobus/S

More details


Remote I/O > SRT (Compobus S)

* Brand new product in its original packaging covered by the warranties and certifications provided by OMRON

Total price: $512.33
Unit price: $512.33

*This price is per unit and is the net value (not including taxes if applicable).

If our price is not the best, please ask us for a quote. Ask for a quotation

Best sellers

▲

More info

▲


Features

IP67 CompoBus/S

Rugged I/O units for field mounting. Omron's unique CompoBus/S is the most efficient I/O bus for machine automation. With free topology and up to 500 m bus length in long-distance mode, it can be used as a remote I/O system. In high-speed mode (100 m max.) the guaranteed sub-millisecond cycle time makes it ideal for efficient machine control. With IP67 slave modules distributed throughout the machine, the need for protective enclosures is minimised.

  • IP67 protection against dust and water
  • Fast cycle time; less than 1 ms for 256 I/O points
  • Easy setup; no software required
  • Choice of 4- and 8-point Digital I/O
  • M12 connectors for easy field wiring

Ordering information

Unit type

Specifications

Size in mm (H×W×D)

Order code

4-point PNP input unit

24 V, 6 mA

114×54×45

SRT2-ID04CL-1

8-point PNP input unit

24 V, 6 mA

114×54×45

SRT2-ID08CL-1

4-point PNP output unit

24 V, 0.5 A per point

114×54×45

SRT2-OD04CL-1

8-point PNP output unit

24 V, 0.5 A per point

114×54×45

SRT2-OD08CL-1

Note:To order models with NPN (sinking) outputs and corresponding inputs (+V common), omit the “-1” from the model code.

Accessories

Unit type

Specifications

Remarks

Order code

CompoBus/S terminator

with M12 plug connector

-

SRS2-1

M12 connector

M12 plug connector (male), screw type

For CompoBus/S 4-wire round cable

XS2G-D4S7

M12 connector

M12 socket connector (female), screw type

For CompoBus/S 4-wire round cable

XS2C-D4S7

M12 T-connector (4-wire)

with two M12 socket connectors (female) + one M12 plug connector (male)

-

XS2R-D427-5

4-wire I/O connection cable

with one M12 plug connector (male), 1 m

-

XS2H-D421-C80-A

4-wire I/O connection cable

with one M12 plug connector (male), 2 m

-

XS2H-D421-D80-A

4-wire I/O connection cable

with one M12 plug connector (male), 5 m

-

XS2H-D421-G80-A

4-wire I/O connection cable

with one M12 socket connector (female) and one M12 plug connector (male), 1 m

-

XS2W-D421-C81-A

4-wire I/O connection cable

with one M12 socket connector (female) and one M12 plug connector (male), 2 m

-

XS2W-D421-D81-A

4-wire I/O connection cable

with one M12 socket connector (female) and one M12 plug connector (male), 5 m

-

XS2W-D421-G81-A

Y-connector for 16-point I/O units

Splits the 2 I/O points per M12 connector to two M12 connectors

-

XS2R-D426-1

Y-connector cable for 16-point I/O units

Splits the 2 I/O points per M12 connector to two M12 connectors, 1 m

-

XS2R-D426-C11-F

M12 connector

M12 plug connector (male), solder type

-

XS2G-D421

M12 connector

M12 socket connector (female), solder type

-

XS2C-D421

IP67 cap for M12 sockets

Metal cap for unused I/O connections

-

XS2Z-12

Datasheet - PDF

▲
Title: Size: Type:
PDF CATALOGO OMRON AUTOMATION EN.pdf 28 Mbytes
PDF CATALOG OMRON EN.pdf 24 Mbytes
SRT2-ID08CL-1 338283 SRT27038D q103_srm1_c0_v2_master_control_unit_datasheet_en.pdf 7 Mbytes SRT2-ID08CL-1 338283 SRT27038D q103_srm1_c0_v2_master_control_unit_datasheet_en.pdf
SRT2-ID08CL-1 338283 SRT27038D w266_compobus_s_operation_manual_en.pdf 8 Mbytes SRT2-ID08CL-1 338283 SRT27038D q103_srm1_c0_v2_master_control_unit_datasheet_en.pdf
