> >>>S8VK-G03024-900 401631 S8VK1112C OMRON Power source 30W/24V/1.3 A DIN rail SIDE
Previous Product Next Product
S8VK-G03024-900 401631 S8VK1112C OMRON Power source 30W/24V/1.3 A DIN rail SIDE View larger
Images are for illustrative purposes only. Please refer to data sheet for details.

S8VK-G03024-900 401631 S8VK1112C OMRON Power source 30W/24V/1.3 A DIN rail SIDE

S8VK-G03024-900

401631

S8VK1112C

OMRON

Available Ship on today

Power source 30W/24V/1.3 A DIN rail SIDE

More details


Power supplies > S8VK-G

* Brand new product in its original packaging covered by the warranties and certifications provided by OMRON

* This article may be obsolete. Ask for a quotation and we will check if there are any units available. If not, one of our technicians will look for an alternative solution.

If our price is not the best, please ask us for a quote. Ask for a quotation

More info

▲


Features

The right power supply for your application

The S8VK-G offers a wide product range (from 15W up to 480W), in a very compact size. It is 13% smaller than comparable power supplies and the smallest on the market of its type.

  • Wide operating temperature range (-40 to +70ºC) to guarantee operation stability
  • Double set of DC output terminals (three for the negative) to provide easy wiring
  • High efficiency (90%) to reduce energy consumption
  • Power Boost functionality (120%)
  • Improved DIN-rail mounting clip to provide better vibration resistance and allow for easy installation

Ordering information

Type

Power ratings

Input voltage

Output voltage

Output current

Size (W × H × D) [mm]

Order code

Standard models

Coated models

Power supply
Single-phase

15 W

100 to 240 VAC

Allowable range:
85 to 264 VAC,
90 to 350 VDC,
2 phases less than 240 VAC

5 V

3 A

22.5 × 90 × 90

S8VK-G01505

S8VK-G01505-400

12 V

1.2 A

S8VK-G01512

S8VK-G01512-400

24 V

0.65 A

S8VK-G01524

S8VK-G01524-400

30 W

5 V

5 A

32 × 90 × 90

S8VK-G03005

S8VK-G03005-400

12 V

2.5 A

S8VK-G03012

S8VK-G03012-400

24 V

1.3 A

S8VK-G03024

S8VK-G03024-400

60 W

12 V

4.5 A

32 × 90 × 110

S8VK-G06012

S8VK-G06012-400

24 V

2.5 A

S8VK-G06024

S8VK-G06024-400

120 W

24 V

5 A

40 × 125 × 113

S8VK-G12024

S8VK-G12024-400

240 W

24 V

10 A

60 × 125 × 140

S8VK-G24024

S8VK-G24024-400

48 V

5 A

S8VK-G24048

S8VK-G24048-400

480 W

24 V

20 A

95 × 125 × 140

S8VK-G48024

S8VK-G48024-400

48 V

10 A

S8VK-G48048

S8VK-G48048-400

Specifications

Item

15 W

30 W

60 W

120 W

240 W

480 W

Efficiency (Typ. at 230 VAC)

80% (24 V)

86% (24 V)

88% (24 V)

89% (24 V)

92% (24 V)

93% (24 V)

Input

Rated input voltage

100 to 240 VAC

Allowable range

85 to 264 VAC, 90 to 350 VDC. 2 phases less than 240 VAC

Output

Voltage adjustment range (with V.ADJ)

-10% to 15%

Input variation influence

0.5% max. (at 85 to 264 VAC input, 100% load)

Load variation Influence

3.0% max. (5 V), 2.0% max. (12 V), 1.5% max. (24, 48 V), at 0% to 100% load

Temperature variation influence

0.05%/°C max.

Overload protection

Yes, 130% of rated current typ.

Power Boost

120% of rated current

Overvoltage protection

Yes

Operating ambient temperature

−40 to 70°C (−40 to 158°F)

Series operation

Yes, up to 2 units

Parallel operation

Yes, up to 2 units

EMI

Conforms to EN 61204-3, EN 55011 Class B

EMS

Conforms to EN 61204-3 high severity levels

Harmonic current emissions

Conforms to EN 61000-3-2

Approved standards

UL: UL 508 (Listing), UL 60950-1, cUL: CSA C22.2 No. 107.1 and No. 60950-1,
UL 1310 Class 2 output for 15 W, 30 W, 60 W
EN/VDE: EN 50178 (=VDE0160), EN 60950-1 (=VDE0805),
Lloyd’s Register

ANSI/ISA 12.12.01

Fulfilled standards

SELV (EN 60950-1/EN 50178/UL 60950-1), PELV(EN 60204-1,EN 50178),
Safety of power transformers (EN 61558-2-16), EN 50274 for terminal parts

Degree of protection

IP20 by EN/IEC 60529

Datasheet - PDF

▲
Title: Size: Type:
S8VK-G03024-900 S8VK1112C 401631 t056_s8vk_g_switch_mode_power_supply_datasheet_en.pdf 4 Mbytes S8VK-G03024-900 S8VK1112C 401631 t056_s8vk_g_switch_mode_power_supply_datasheet_en.pdf
