PL11 PL 1006M OMRON Circular 11-pin

H2C Motor timers
DIN-sized (48×48) motor timer with variable time ranges
This motor timer series provides you with many features, such as ON-delay,
time indicator, moving pointer and synchronous motor. Moreover, the LED indicator shows the time operation, time range and the rated voltage.
• DIN-sized 48 × 48mm
• Front-panel/plug-in/DIN-rail
• All supply voltages available
• 0.2 s to 30 h
• SPDT, 6A at 250VAC
Ordering information
Operation/resetting system Internal connection Terminal Time-limit contact
Instantaneous Time range code Order code contact
Time-limit operation/
electric resetting
Time-limit operation/
self-resetting
Separate motor and clutch connec- tion
Separate motor and clutch connec- tion
11-pin socket SPDT SPDT 1.25 s to 30 h in 5 ranges
0.2 s to 6 h in 5 ranges
0.5 s to 12 h in 5 ranges
11-pin socket SPDT SPDT 1.25 s to 30 h in 5 ranges
0.2 s to 6 h in 5 ranges
0.5 s to 12 h in 5 ranges
H2C-RSA 110AC H2C-RSA 220AC H2C-RSA 24AC H2C-RSB 110AC H2C-RSB 220AC H2C-RSB 24AC H2C-RSC 110AC H2C-RSC 220AC H2C-RSC 24AC H2C-SA 110AC H2C-SA 220AC H2C-SA 24AC H2C-SB 110AC H2C-SB 220AC H2C-SB 24AC H2C-SC 110AC H2C-SC 220AC H2C-SC 24AC
Note: Other voltages available on request
Accessories
Name/specifications Order code
Name/specifications Order code
DIN-rail mounting/
front-connecting socket
8-pin, finger safe type P2CF-08-E
11-pin, finger safe type P2CF-11-E
Hold-down clip (pair) For PL08 and PL11 sockets Y92H-1
For PF085A socket Y92H-2
Back-connecting socket 8-pin, screw terminal P3G-08
11-pin P3GA-11
Flush mounting adapter Y92F-30
Time setting ring Y92A-Y1
Specifications
Operating voltage range 85 to 110% of rated supply voltage
Reset voltage 10% max. of rated supply voltage
Reset time Min. power-opening time: 0.5 s, min. pulse width: 0.5 s
Control outputs 6 A at 250 VAC, resistive load (cos = 1)
Mounting method Flush mounting (except for H2C-F/-FR models), surface-mounting, DIN-rail mounting
Life expectancy Mechanical: 10,000,000 operations min.
Electrical: 500,000 operations min.
Motor life expectancy 20,000 h
Accuracy of operating time ±0.5% FS max. (±1% max. at 0.2 to 6 s for the time range code B or at 0.5 to 12 s for the time range code C)
Setting error ±2% FS max. Reset time 0.5 s max. Influence of voltage ±1% FS max. Influence of temperature ±2% FS max.
Ambient temperature Operating: –10 to 50°C Case color Light grey (Munsell 5Y7/1) Degree of protection IP40 (panel surface)
Size in mm (H×W×D) 48×48×77.5
