P2R-08P P2R 6027E P2R08PBYOMZ OMRON Base G2R-2-S 8 pin Terminals PCB View larger
Images are for illustrative purposes only. Please refer to data sheet for details.

P2R-08P P2R 6027E P2R08PBYOMZ OMRON Base G2R-2-S 8 pin Terminals PCB

P2R-08P

P2R 6027E

P2R08PBYOMZ

OMRON

10

Base G2R-2-S 8 pin Terminals PCB

Socket, back-connecting, 8-pin, PCB terminals

More details


Relays > Relay socket

Relay sockets > Other sockets

Brand new product in its original packaging covered by the warranties and certifications provided by OMRON

Total: $39.01
Unit price: $3.90
This price is per unit and is the net value (not including taxes if applicable).

If our price is not the best, please ask us for a quote. Ask for a quotation

Best sellers

▲

More info

▲


Features

Plug-in relay with enhanced features covers a wide range of applications

G2RS series, which comes as standard with a mechanical indicator and nameplate covering a wide range of interface applications. Optionally available with gold clad contacts and diode, whilst the socket and crossbar range offer maximum flexibility during installation.

  • SPDT type 10A / DPDT type 5 A
  • Mechanical Flag, LED indicator and momentary / lockable testbutton optional
  • Transparent housing
  • Screwless clamp terminal sockets available
  • Space saving – 16 mm width (including sockets)

Ordering information

Contact form

Diode

LED indicator

Test button

Gold clad 3 µm

Order code

( ___ = coil voltage + AC/DC)

Common coil voltages1

DC

AC

SPDT (1-pole)

no

no

no

no

G2R-1-S___(S)

24

230

yes

G2R-1-SN___(S)

12, 24

24, 110, 230

yes

G2R-1-SNI___(S)

12, 24

12, 24, 110, 230

yes

G2R-1-SNI-AP3___(S)

-

230

yes

no

no

G2R-1-SND___(S)

12, 24

-

yes

G2R-1-SNDI___(S)

24

-

yes

G2R-1-SNDI-AP3___(S)

24

-

DPDT (2-pole)

no

no

no

no

G2R-2-S___(S)

24

24, 110, 240

yes

G2R-2-SN___(S)

12, 24, 48

24, 110, 230

yes

G2R-2-SN-AP3___(S)

24

-

yes

no

G2R-2-SNI___(S)

12, 24

12, 24, 110, 230

yes

G2R-2-SNI-AP3___(S)

-

230

yes

no

no

no

G2R-2-SD___(S)

-

-

yes

G2R-2-SND___(S)

12, 24

-

yes

G2R-2-SND-AP3___(S)

24

-

yes

no

G2R-2-SNDI___(S)

12, 24

-

yes

G2R-2-SNDI-AP3___(S)

24

-

Sockets & accessories

For type

Order code

DIN rail

PCB

Screwless clamp

Screw
(plate clamp)

Screw (box clamp)

Soldering

Socket

Clip

Cross bar
AC type

Cross bar
DC type

Name plate

Socket

Socket

Clip

Name plate

Socket

G2R-1-S

P2RF-05-S

P2CM-S

P2RM-SR

P2RM-SB

R99-11

P2RF-05-E

P2RF-05-ESS

P2CM-ESS

PYC-TR

P2R-05P

G2R-2-S

P2RF-08-S

P2CM-S

P2RM-SR

P2RM-SB

R99-11

P2RF-08-E

P2RF-08-ESS

P2CM-ESS

PYC-TR

P2R-08P

For the new push-in plus technology socket go to.

Specifications

Coil ratings

Rated voltage

Must operate voltage

Must release voltage

Max. voltage

Power consumption (approx.)

% of rated voltage

AC

24 V, 110 V, 120 V, 230 V, 240 V

80% max.

30% max.

110%

0.9 VA (60 Hz)

DC

6 V, 12 V, 24 V, 48 V

70% max.

15% max.

110%

0.53 W

Contact ratings

Number of poles

1-pole

2-pole

Load

Resistive load
(cosϕ = 1)

Inductive load
(cosϕ = 0.4; L/R = 7)

Resistive load
(cosϕ = 1)

Inductive load
(cosϕ = 0.4; L/R = 7)

Rated load

10 A at 250 VAC

10 A at 30 VDC

7.5 A at 250 VAC

5 A at 30 VDC

5 A at 250 VAC

5 A at 30 VDC

2 A at 250 VAC

3 A at 30 VDC

Rated carry current

10 A

5 A

Max. switching voltage

440 VAC, 125 VDC

380 VAC, 125 VDC

Max. switching current

10 A

5 A

Max. switching power

2,500 VA, 300 W

1,875 VA, 150 W

1,250 VA, 150 W

500 VA, 90 W

Failure rate (reference value)

100 mA at 5 VDC

10 mA at 5 VDC

Mechanical life

AC: 10,000,000 operations min., DC: 20,000,000 operations min.

Electrical life

100,000 operations min.

Technical data

Item

1-pole

2-pole

Contact material

AgSnIn

Operating time

15 ms max.

15 ms max.

Release time

AC: 10 ms max., DC: 5 ms max.

AC: 15 ms max., DC: 10 ms max.

Dielectric strength

5,000 VAC (coil-contact)

5,000 VAC (coil-contact)

Ambient temperature

Operating: -40 to 70°C (no icing or condensation)

Size in mm (H×W×D)

35.5×13×29

1.Other coil voltages available. Please see specifications.


ETIM for 113545 Relays (EC001456)
Feature Name Feature Value
Mounting method (EF000003) Other
Type of electric connection (EF003961) PCB connection
Function extension possible (EF003444) No
With detachable clamps (EF003340) No
Number of pins (EF005580) 8
Width (EF000008) 14 mm
Height (EF000040) 15 mm
Depth (EF000049) 32 mm

Datasheet - PDF

▲
Title: Size: Type:
PDF CATALOG OMRON 2024 EN.pdf 25 Mbytes
P2R-08P P2R08PBYOMZ P2R 6027E g2rs_series_brochure_en.pdf 303 Kbytes P2R-08P P2R08PBYOMZ P2R 6027E g2rs_series_brochure_en.pdf
