Programmable Temperature Controller (Digital Controller) E5AN-HT/E5EN-HT (96 x 96 mm and 48 x 96 mm) CSM_E5AN-HT_E5EN-HT_DS_J_1_4 Programmable Controllers Join the Series! Program up to 256 segments and take advantage of the high cost performance of the new LCD that improves both the field of view and contrast. • Set up to 8 programmed patterns with up to 32 segments (steps) each. • High-resolution display with 5 digits/0.01°C display. • High-speed sampling cycle of 60 ms. • High Accuracy Thermocouple/Pt input: ±0.1% of PV Analog input: ±0.1% FS • Universal inputs on all models (thermocouple, PT, or analog input) to handle various sensors with one Controller. Models also available with Remote SP. • A PV/SV-status display function can be set to automatically alternate between displaying the status of the Temperature Controller (auto/ manual, RUN/RESET, and alarms) and the PV or SV. • Flexible contact outputs with logic operations (AND, OR, and delays) set from the Support Software (CX-Thermo version 96 × 96 mm E5AN-HT 48 × 96 mm E5EN-HT 4.3). Program settings can be managed. • An infrared ports enables communications from the front panel. • Preventive maintenance for relays in the Temperature Controller using a Control Output ON/OFF Counter. • Model available with position-proportional control Main I/O Functions For the most recent information on models that have been certified for safety standards, refer to your OMRON website. Refer to Safety Precautions for [email protected][email protected]/ [email protected] Refer to Operation for [email protected][email protected][email protected] for operating procedures. Remote SP Input . One Event Inputs • None • Two • Four Universal Sensor Inputs • Universal thermocouple/ E5AN-HT E5EN-HT Three displays for simultaneous display of the PV, SV, program, and segment. 5-digit Display with high resolution of 0.01°C . Programmable function 8 programs × 32 Pt/analog (current/voltage) inputs. Indication Accuracy . Thermocouple/Pt input: ±0.1% of PV . Analog input: ±0.1% FS Sampling Period . 60 ms Infrared port USB Control Output 2 Output Unit • Relay output Auxiliary Outputs • Two • Three Computer Support Software CX-Thermo segments • Auto/manual switching • Temperature Controller status display • Simple program function • Logic operations • Control output ON/OFF count alarm • PV change rate alarm . Models available with PF Key (Programmable key function) • Voltage output (for driving SSR) • Current output • Linear voltage output Control Output 1 Output Unit • Relay output • Voltage output (for driving SSR) • Current output • Linear voltage output RS-485, RS-422, or RS-232C communications 1
