D5A-3300 D5A 3300M D5A3300 OMRON FC High precision 1 micron Plunger needle M8
D5A-3300
D5A 3300M
D5A3300
OMRON
FC High precision 1 micron Plunger needle M8
Limit switch, high precision, pin plunger, M8, 0.98 N Operating force, SPST-NC, prewired 1 m
Sensors > End switch
Industrial Limit switches / Pushbuttons > Other Industrial Limit switches
Brand new product in its original packaging covered by the warranties and certifications provided by OMRON
Best sellers
▲More info
▲Area monitoring fiber sensor heads
The area monitoring fibers allow the detection of objects passing anywhere through the detection range and can be used for height comparisons of different objects.
- Area monitoring up to 70 mm height
- Multi-beam sensor with 4 seperate heads for flexible detection points
- Standard or high flex fibers
Two state detections
The two outputs of the E3X-DA-S can be used to detect two different light levels.
Position compensation
In combination with the twin output function of the E3X-DA-S amplifier, the diffuse reflective area monitoring fibers can detect very small objects (e.g. needles) and a second state (e.g cover present). The area beam compensates for position variations at high speed.
| Feature Name | Feature Value |
|---|---|
| Explosion safety category for dust (EF003998) | None |
| Construction type housing (EF004008) | Other |
| Degree of protection (NEMA) (EF011959) | Other |
| Coating housing (EF001601) | Other |
| Degree of protection (IP) (EF005474) | IP67 |
| Alignment of the control element (EF008793) | Other |
| Type of control element (EF006976) | Plunger |
| Type of interface for safety communication (EF003956) | None |
| Type of electric connection (EF003961) | With cable preassembled |
| Type of interface (EF006977) | None |
| Switching function (EF000189) | Other |
| Housing material (EF001596) | Metal |
| Explosion safety category for gas (EF003997) | None |
| Switching function latching (EF007447) | No |
| With status indication (EF001602) | No |
| Suitable for safety functions (EF001597) | No |
| Forced opening (EF006694) | No |
| Output electronic (EF006987) | No |
| Number of contacts as change-over contact (EF008257) | 0 |
| Number of contacts as normally open contact (EF008256) | 0 |
| Number of safety auxiliary contacts (EF006940) | 0 |
| Number of contacts as normally closed contact (EF008255) | 1 |
| Diameter sensor (EF007111) | 8 mm |
| Length of sensor (EF007334) | 23 mm |
| Ambient temperature during operating (EF007515) | -20 °C |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGO OMRON AUTOMATION EN.pdf | 28 Mbytes |
|
| PDF CATALOG OMRON 2024 EN.pdf | 25 Mbytes |
|
| D5A-3300 D5A3300 D5A 3300M e56e_fiber_optic_sensors_group_catalogue_en.pdf | 8 Mbytes |
|
