OMRONSafetyD4DL/DS/DH/DR/GL/NL/NH/NSD4NS-2DF D4NS0014M D4NS2DF OMRON Safety interlock switch, 3NC, 10 A, single G1/2 conduit
OMRON D4NS-2DF D4NS0014M D4NS2DF - Image 1

Images are for illustrative purposes only. Please refer to data sheet for details.

D4NS-2DF D4NS0014M D4NS2DF OMRON Safety interlock switch, 3NC, 10 A, single G1/2 conduit

Reference: D4NS-2DF

Code: D4NS0014M

Catalog Number: D4NS2DF

Manufacturer: OMRON

Description:

Safety interlock switch, 3NC, 10 A, single G1/2 conduit
Safety interlock switch, 3NC (slow-action), 10 A, single G1/2 conduit,

Categories:

  • Sensors > Position switch with separate actuator
  • OMRON > Safety > D4DL/DS/DH/DR/GL/NL/NH/NS

Brand new product in its original packaging covered by the warranties and certifications provided by OMRON

  • More Info
  • ETIM
  • PDF
  • Reviews
Guarantee, repair and return.

Unit Price: 34,68 €

This price is per unit and is the net value (not including taxes if applicable).

Calculate price by quantity

QuantityPrice

Standard lead time: 4-5 weeks.

  • These delivery times are an estimate any may vary when the item order has been processed.

LAST VIEWED

MORE INFO

Specifications

Door switch typeKey-operated
Guard-lock
Material housingResin
Material headResin
Ambient temperature (operating)-30-70 °C
Direction of operationAdjustable
Door contacts NC3
Door contacts NO0
Switch actionSlow action
Make before break
With LED indicator
Connection methodTerminal block
Cable length0 m
Degree of protection (IP)IP67
Conduit sizeG1/2
Number of conduits1
ShapeCuboid
Overall length96 mm
Height of sensor30 mm
Width sensor31 mm

ETIM for 162290 Sensors (EC002592)

Feature nameExplosion safety category for dust (EF003998)
Feature valueNone
Feature nameConstruction type housing (EF004008)
Feature valueCuboid
Feature nameType of switching contact (EF003591)
Feature valueSlow-action switch
Feature nameDegree of protection (NEMA) (EF011959)
Feature valueOther
Feature nameCoating housing (EF001601)
Feature valueOther
Feature nameDegree of protection (IP) (EF005474)
Feature valueIP67
Feature nameType of interface for safety communication (EF003956)
Feature valueNone
Feature nameType of electric connection (EF003961)
Feature valueOther
Feature nameType of interface (EF006977)
Feature valueNone
Feature nameHousing material (EF001596)
Feature valueOther
Feature nameExplosion safety category for gas (EF003997)
Feature valueNone
Feature nameWith status indication (EF001602)
Feature valueNo
Feature nameSuitable for safety functions (EF001597)
Feature valueYes
Feature nameForced opening (EF006694)
Feature valueNo
Feature nameNumber of contacts as change-over contact (EF008257)
Feature value0
Feature nameNumber of contacts as normally open contact (EF008256)
Feature value0
Feature nameRated operation current Ie at AC-15, 230 V (EF001385)
Feature value3 A
Feature nameRated operation current Ie at DC-13, 125 V (EF007085)
Feature value0.27 A
Feature nameNumber of safety auxiliary contacts (EF006940)
Feature value0
Feature nameRated operation current Ie at DC-13, 230 V (EF001386)
Feature value0.27 A
Feature nameNumber of contacts as normally closed contact (EF008255)
Feature value3
Feature nameWidth sensor (EF007094)
Feature value31 mm
Feature nameHeight of sensor (EF007283)
Feature value30 mm
Feature nameLength of sensor (EF007334)
Feature value96 mm
Feature nameAmbient temperature during operating (EF007515)
Feature value-30 °C
