> OMRON>Control Systems>C200H>C200H-TS102 159384 OMRON 4 Pt100 Inputs
Previous Product Next Product
C200H-TS102 159384 OMRON 4 Pt100 Inputs View larger
Images are for illustrative purposes only. Please refer to data sheet for details.

C200H-TS102 159384 OMRON 4 Pt100 Inputs

C200H-TS102

159384

OMRON

4 Pt100 Inputs

More details


Control Systems > C200H

Brand new product in its original packaging covered by the warranties and certifications provided by OMRON

* This article may be obsolete. Ask for a quotation and we will check if there are any units available. If not, one of our technicians will look for an alternative solution.

If our price is not the best, please ask us for a quote. Ask for a quotation

Best sellers

▲

More info

▲


Features

Fastest compact machine controller

Designed for compact machines, it combines the size of a micro PLC and the power of a modular PLC. Four built-in high-speed counters and four pulse outputs are ideal for multi-axis positioning control. The CP1H-XA comes with 4 analog inputs and 2 analog outputs built-in. This makes it suitable for simple loop control, using the PLC's advanced PID control function with auto-tuning. The CP1H can be expanded with CP1W I/Os and supports up to 2 CJ1 special I/O units. This means that it is open to popular fieldbuses and supports all communication units of the CJ1 series.

  • Up to 1 MHz for inputs/outputs
  • CJ1M compatible instruction set and execution speed
  • 4 analog inputs and 2 analog outputs for the XA model
  • USB port for easy communication, programming and configuration
  • Supports PROFIBUS, DeviceNet, CAN and Ethernet

Ordering information

CP1H CPU

Digital input

Digital output

Max. I/O points (incl. expansions)

Input/output functions

Output type

Power supply

PLC port

Expandability

Program capacity

Data memory capacity

Logic execution speed

Order code

Y-type with 20 I/O points

12

8

300

4 Encoder inputs
(2 × 1 MHz +
2 × 100 kHz)
4 Pulse outputs
(2 × 1 MHz +
2 × 100 kHz)
6 Interrupts/counters

Transistor (sinking)

20.4 to 26.4 VDC

USB

Up to
7 expansion units1

20K steps

32K words

0.1 μs

CP1H-Y20DT-D

X-type with 40 I/O points

24

16

320

4 Encoder inputs (100 kHz)
8 Interrupts/counters

Relay

84 to 264 VAC

CP1H-X40DR-A

4 Encoder inputs (100 kHz)
4 Pulse outputs (100 kHz)
8 Interrupts/counters

Transistor (sinking)

20.4 to 26.4 VDC

CP1H-X40DT-D

Transistor (sourcing)

CP1H-X40DT1-D

XA-type with 40 I/O points and analog
I/O

4 Encoder inputs (100 kHz)
8 Interrupts/counters
4 Analog inputs (1/12,000)
2 Analog outputs (1/12,000)

Relay

84 to 264 VAC

CP1H-XA40DR-A

4 Encoder inputs (100 kHz)
4 Pulse outputs (100 kHz)
8 Interrupts/counters
4 Analog inputs (1/12,000)
2 Analog outputs (1/12,000)

Transistor (sinking)

20.4 to 26.4 VDC

CP1H-XA40DT-D

Transistor (sourcing)

CP1H-XA40DT1-D

Note:Some expansion units count for 2 unit numbers (eg. CP1W-AD042, CP1W-DA042, CP1W-TS003 and CP1W-TS102) but only 7 expansion unit numbers can be allocated
in a CP1H PLC's configuration. There are more limitations for expansion units like, max. I/O words and total DC power consumption. See manual for more information.

Accessories

Type

Remarks

Order code

Memory cassette

512K words (upload/download program)

CP1W-ME05M

USB programming cable

A-type male to B-type male (length: 1.8 m)

CP1W-CN221

RS-232C option board

D-Sub, 9 pins, female (15 m max.)

CP1W-CIF01

RS-422A/485 option board

Terminal block (50 m max.)

CP1W-CIF11

RS-422A/485 (isolated) option board

Terminal block (500 m max.)

CP1W-CIF12

Ethernet option board

100/10Base-TX (Auto-MDIX)

CP1W-CIF41

LCD display

4 rows × 12 characters

CP1W-DAM01

Expansion I/O connecting cable

80 cm cable to connect CP1W expansion units

CP1W-CN811

CJ1 expansion unit adapter

Unit to connect CJ1 Special I/O units

CP1W-EXT01

Battery

For replacement purpose

CJ1W-BAT01

1.CP1H CPU series can be expanded with CP1W expansion units (up to 7 units) and CJ1 Special I/O units (up to 2 units).


Datasheet - PDF

▲
Title: Size: Type:
PDF CATALOGO OMRON AUTOMATION EN.pdf 19 Mbytes
PDF CATALOG OMRON 2024 EN.pdf 25 Mbytes
C200H-TS102 159384 cp1_series_brochure_en.pdf 1 Mbytes C200H-TS102 159384 cp1_series_brochure_en.pdf
C200H-TS102 159384 p080_cp_series_cp1h_cpu_unit_datasheet_en.pdf 2 Mbytes C200H-TS102 159384 cp1_series_brochure_en.pdf
