V-TEC VM16+ OR 7205657 OBO BETTERMANN V-TEC VM16+ OR cable gland, with M16 Polyamide lock nut, PA
V-TEC VM16+ OR
7205657
OBO BETTERMANN
10
V-TEC VM16+ OR cable gland, with M16 Polyamide lock nut, PA
Cable glands V-TEC VM16+ OR with M16 orange locknut
Cable gland with locknut as a set. Robust cap nut cable gland with metric connecting thread to IEC 423, including pre-mounted locknut.For high tightness requirements. Strain relief, torsion protection and tightness over the whole clamping area. Sealing ring made of polychloroprene/acrylonitrile butadiene rubber. Moulded shaped sealing lip on intermediate support, no connection thread sealing ring required.VDE-tested according to DIN EN 50262, protection rating IP68 at 5 bar for 1 hr.For maintenance of electrical function according to DIN 4102 Part 12 in connection with the closed junction boxes of the FireBox T series.Colour: Pastel orange.
BSS fire protection systems - OBO BETTERMANN
Brand new product in its original packaging covered by the warranties and certifications provided by OBO BETTERMANN
Related products
▲Best sellers
▲More info
▲| Bend protection | no |
|---|---|
| CO2 Footprint (GWP) Cradle-to-Gate | 0,0336 kg CO2e / 1 Piece |
| Colour | Pastel orange; RAL 2003 |
| Dimension | M16 |
| Dimension E1 (mm) | 22 mm |
| Dimension E2 | 25 mm |
| Dimension G | M16 x 1,5 mm |
| Dimension L max. | 23,5 mm |
| Dimension L min. | 21,5 mm |
| Dimension L1 | 8 mm |
| Dimension L2 | 5 mm |
| Dimension L3 | 5 mm |
| Fibre-glass reinforced | no |
| Flame-resistant | acc. to VDE 0471/DIN 695 Part 2-1, test temperature 650°C |
| Flat cable gland | no |
| For Ex zone | Without |
| For Ex zone dust | Without |
| For Ex zone gas | Without |
| Halogen-free | yes |
| Impact-resistant | no |
|---|---|
| Material | Polyamide |
| Permitted temperature range, max. | 65 °C |
| Permitted temperature range, min. | -20 °C |
| Protection rating | IP68 |
| Sealing area D, max. | 10 mm |
| Sealing area D, min. | 4,5 mm |
| Sealing insert, multiple | no |
| Splittable gland | no |
| Strain relief option | yes |
| Thread | M16 x 1,5 |
| Thread increase | 1,5 mm |
| Thread length | 9 mm |
| Thread type | Metric |
| WAF | 20 |
| WAF 1 | 20 mm |
| WAF 2 | 22 mm |
| With locknut | yes |
| Feature Name | Feature Value |
|---|---|
| Thread type (EF001758) | Metric |
| Pitch thread (EF003712) | 1.5 mm |
| Thread length (EF000368) | 9 mm |
| Wrench width (EF000177) | 20 mm |
| Suitable for cable diameter (EF005466) | 4.5 mm |
| Material (EF002169) | Plastic |
| Material quality (EF001257) | Polyamide (PA) |
| Halogen free (EF000025) | Yes |
| Degree of protection (IP) (EF005474) | IP68 |
| Shock resistant (EF000084) | No |
| Colour (EF000007) | Orange |
| RAL-number (EF000116) | 2003 |
| Bend radius protection/trumpet flare (EF000734) | No |
| With locknut (EF005049) | Yes |
| Multi seal area (EF005004) | No |
| Flat cable coupling (EF004685) | No |
| With strain relief (EF000878) | Yes |
| Separable screw gland (EF005337) | No |
| Operating temperature (EF001742) | -20 °C |
| For Ex-zone gas (EF005728) | None |
| For Ex-zone dust (EF008404) | None |
