2CLA220210A1101 2202.1 BA NIESSEN Conmutador 16A
Reference: 2CLA220210A1101
Code: 2202.1 BA
Manufacturer: NIESSEN
Description:
Conmutador 16A
16A Switch
Insert/cover Rocker/button, Two-way switch with Glow lamp Alpin White - Stylo
Categories:
- NIESSEN > Flush-mounting series
Brand new product in its original packaging covered by the warranties and certifications provided by NIESSEN
- More Info
- Reviews
* This article may be obsolete. Ask for a quotation and we will check if there are any units available. If not, one of our technicians will look for an alternative solution.
Ask for a quotation and we will check if there are any units available. If not, one of our technicians will look for an alternative solution.
MORE INFO
| Installation | |
|---|---|
| Mounting Type | Flush Mounted |
| Type of Fastening | Engage (Snap) |
| Environmental | |
| Ambient Air Temperature | Operation -5 ... +35 °C |
| Storage -5 ... +50 °C | |
| Degree of Protection | IP20 |
| Technical | |
| Function | Function lighting: Orientation |
| Number of Rocker Switches | 1 |
| Wiring Configuration | Two-way switch |
| Actuator Type | Rocker/button |
| Connection Type | Plug Clamp |
| Lamp Type | Glow lamp |
| Illumination | Optional |
| Number of Batteries | 0 |
| Electrical | |
| Rated Voltage (Ur) | 250 V |
| Rated Current (In) | 16 A |
| Maximum Switching Current | Fluorescent Lamps 16 |
| Design | |
| Design Range | Stylo |
| Surface Finishing | Untreated |
| Glossy | |
| Material | Plastic |
| Label Space Provided | Without Label Space |
| Color | Alpin White |
| Number of Modules | 2 |
| Dimensions | |
| Product Net Width | 44 mm |
| Product Net Height | 44 mm |
| Product Net Weight | 0.048 kg |
| Ordering | |
| Replaced Product ID (OLD) | 2CL0220211 |
| Material Compliance | |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108468A3363 |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| WEEE B2C / B2B | Business To Consumer |
| Certificates and Declarations | |
| EU Data Act Applicability and Compliance | Not Applicable |
| External Classifications and Standards | |
| ETIM 9 | EC001590 - Installation switch |
| ETIM 10 | EC001590 - Installation switch |
| UNSPSC | 39122226 |
DATASHEET - PDF
