2CKA006800A3042 8141.2 NIESSEN Sensor de movimiento
2CKA006800A3042
8141.2
NIESSEN
Sensor de movimiento
Motion Sensor
Relay insert 1-gang 230 V
Domestic switching devices > Electronic switch
Home Automation
Brand new product in its original packaging covered by the warranties and certifications provided by NIESSEN
Best sellers
▲More info
▲| Installation | |
|---|---|
| Instructions and Manuals | 2CKA000073B5091 |
| 2CKA000073B5092 | |
| 2CKA000073B5093 | |
| 2CKA000073B5094 | |
| Instructions and Manuals (Part 2) | 2CKA000073B5216 |
| Mounting Type | Flush Mounted |
| Type of Fastening | Mounting with Screw |
| Mounting with Claw | |
| Modular Components Included | Flush Mounted Insert with Mounting Plate |
| Environmental | |
| Ambient Air Temperature | Operation -25 ... +55 °C |
| Technical | |
| Number of Outputs | 1 |
| Number of Inputs | 1 |
| Product Range | flexTronics |
| flexTronics Wireless | |
| free@home Wireless | |
| free@home | |
| Connection Type | Pin |
| Terminal Type | Screw Terminals |
| Electrical | |
| Rated Voltage (Ur) | 230 V |
| Rated Current (In) | 10 A |
| Rated Frequency (f) | 50 Hz |
| Maximum Switching Power | Fluorescent Lamp 2300 V·A |
| Halogen Low Voltage Lamps with Electronical Transformers (Capacitive Loads) 2300 V·A | |
| Halogen Low Voltage Lamps with Magnetic Transformers (Inductive Loads) 2300 V·A | |
| Incandescent Lamp or Halogen High Voltage Lamps 2300 W | |
| LEDi 300 V·A | |
| Load Type | Universal and LED Retrofit |
| LEDi/CFLi | |
| Incandescent Lamp | |
| Halogen Lamp, High Voltage | |
| Halogen Lamp, Low Voltage | |
| Fluorescent Lamp | |
| Power Loss | 0.3 W |
| Number of Contacts NO | 1 |
| Design | |
| Design Range | Platform 63 |
| Busch-balance SI | |
| Reflex SI | |
| Busch-Duro 2000 SI | |
| Busch-art linear | |
| future linear | |
| Busch-axcent | |
| Pure Stainless Steel | |
| solo | |
| carat | |
| Busch-Dynasty | |
| Trevion | |
| Design Range Variant | Busch-Duro 2000 SI |
| Busch-Duro 2000 SI Linear | |
| Reflex SI | |
| Reflex SI Linear | |
| Busch-art linear | |
| Busch-art linear - with Decor Ring | |
| Busch-art linear - pur | |
| future | |
| future linear | |
| Busch-axcent | |
| Busch-axcent pur | |
| Number of Gangs | 1-gang |
| Dimensions | |
| Product Net Width | 0.14 m |
| Product Net Height | 0.227 m |
| Product Net Depth / Length | 0.181 m |
| Product Net Weight | 148.5 g |
| Built-In Depth (t2) | 25 mm |
| Engineering | |
| Building Information Modeling – BIM | 9AKK108471A9951 |
| Ordering | |
| Replaced Product ID (OLD) | 2CKA000043B6012,2CKA006800A2160,2CKA006400A0085 |
| E-Number (Finland) | 2619440 |
| E-Number (Norway) | 1416510 |
| E-Number (Sweden) | 1301520 |
| Circular Value | |
| Environmental Product Declaration - EPD | 9AKK108469A3355 |
| Material Compliance | |
| RoHS Declaration | 2CKA200000E7469 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| REACH Declaration | 2CKA309999E9999 |
| REACH Information | False - does not contain substances > 0.1 mass percentage |
| REACH Date | 20250901 |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108468A3363 |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| WEEE B2C / B2B | Business To Consumer |
| Certificates and Declarations | |
| Declaration of Conformity - CE | 2CKA100000E4275 |
| EU Data Act Compliance Declaration | 9AKK108471A4355 |
| EU Data Act Applicability and Compliance | Applicable - Compliant |
| External Classifications and Standards | |
| ETIM 9 | EC001588 - Electronic switch |
| ETIM 10 | EC001588 - Electronic switch |
| eClass | V11.0 : 27144054 |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE KNX & SOLUTION FOR BUILDINGS EN.pdf | 88 Mbytes |
|
| PDF CATALOGUE NIESSEN EN .pdf | 36 Mbytes |
|
| 2CKA006800A3042 8141.2 EN_2CKA006800A3042.pdf | 134 Kbytes |
|
