NIESSENHome Automation2CDG510016R0011 BI-M-4.20.1.1 NIESSEN DIN binary input 4 channels, 24VDC
NIESSEN 2CDG510014R0011 BI-M-4.20.1.1 - Image 1

Images are for illustrative purposes only. Please refer to data sheet for details.

2CDG510016R0011 BI-M-4.20.1.1 NIESSEN DIN binary input 4 channels, 24VDC

Reference: 2CDG510014R0011

Code: BI-M-4.20.1.1

Manufacturer: NIESSEN

Description:

DIN binary input 4 channels, 24VDC
BI-M-4.230.1.1 Binary Input, 4-fold, 10-230 V, Manual Operation, MDRC

Categories:

  • Installation bus systems > Binary input for bus system
  • NIESSEN > Home Automation

Brand new product in its original packaging covered by the warranties and certifications provided by NIESSEN

  • More Info
  • Reviews
Guarantee, repair and return.

Unit Price: 144,39 €

This price is per unit and is the net value (not including taxes if applicable).

Calculate price by quantity

QuantityPrice

Standard lead time: 10 days.

  • These delivery times are an estimate any may vary when the item order has been processed.

LAST VIEWED

MORE INFO

Installation
Mounting TypeDIN-Rail
Environmental
Degree of ProtectionIP20
Technical
Number of LEDs1
Number of Inputs4
Compatible Bus Systemsfree@home (TP)
Product Rangefree@home
Transmission StandardTwisted Pair Wiring
Manual OperationNo
Terminal TypeBus Connection
Electrical
Voltage Range10 ... 230 V AC/DC
Input Voltage (Uin)10 ... 230 V
Input Voltage TypeAC/DC
Power Loss0.25 W
Design
Colorgrey
Dimensions
Width in Number of Modular Spacings2
Product Net Width90 mm
Product Net Height63.5 mm
Product Net Depth / Length36 mm
Product Net Weight0.1 kg
Built-In Depth (t2)64.5 mm
Dimension Diagram2CDC072025F0017
Ordering
E-Number (Finland)2815932
E-Number (Norway)4549505
E-Number (Switzerland)405621125
Circular Value
Environmental Product Declaration - EPD9AKK108472A2713
Material Compliance
RoHS Declaration9AKK108472A2583
RoHS InformationFollowing EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
REACH Declaration9AKK108471A7754
REACH InformationTrue - contains substances > 0.1 mass percentage
REACH Date20251203
Conflict Minerals Reporting Template (CMRT)9AKK108468A3363
WEEE Category5. Small Equipment (No External Dimension More Than 50 cm)
WEEE B2C / B2BBusiness To Consumer
Certificates and Declarations
EU Data Act Compliance Declaration9AKK108471A4355
Cyber Security Software Support Period2
EU Data Act Applicability and ComplianceApplicable - Compliant
External Classifications and Standards
ETIM 9EC000688 - Binary input for bus system
ETIM 10EC000688 - Binary input for bus system
eClassV11.0 : 27143121

DATASHEET - PDF

Title
Size
Type
PDF CATALOGUE KNX & SOLUTION FOR BUILDINGS EN
88 Mbytes
PDF CATALOGUE NIESSEN EN
36 Mbytes
