EWT-PP-M10/P7 83204250 MURRPLASTIK Conduits and fitting systems Type EWT-PP split-flex® Standard corrugation Bla View larger
Images are for illustrative purposes only. Please refer to data sheet for details.

EWT-PP-M10/P7 83204250 MURRPLASTIK Conduits and fitting systems Type EWT-PP split-flex® Standard corrugation Bla

83204250

MURRPLASTIK

50

Conduits and fitting systems Type EWT-PP split-flex® Standard corrugation Black

More details


Corrugated pipes and fittings

* Brand new product in its original packaging covered by the warranties and certifications provided by MURRPLASTIK

Total price: $165.58
Unit price: $3.31

Quantity Price
50+$3.31
100+$2.84
150+$2.64
200+$2.63
*This price is per unit and is the net value (not including taxes if applicable).

If our price is not the best, please ask us for a quote. Ask for a quotation

Best sellers

▲

More info

▲


The EWT-PP cable protection conduits are made of specially modified polypropylene. The material is phosphor and cadmium-free. For static applications involving light to medium mechanical loads.

The EWT-PP cable protection conduits consist of a two-piece slotted corrugated tube system and feature the following advantages:

Corrugated tubes can be opened and closed at any time.

Mounting of pre-assembled cables

Retrofitting or repair in mechanical and plant engineering

Halogen-free

UV-resistant

-40°C – 130°C, transient / short term 150°C

i.a.w. UL94 V2

Type Order No. Colour A Ø mm B Ø mm R stat. mm R dyn. mm Weight kg/100m Pack m

Standard corrugation

EWT-PP-M10/P7 83204250 Black 5.7 11.5 55 190 3.2 50
EWT-PP-M12/P9 83204252 Black 7.9 12.9 60 210 4.0 50
EWT-PP-M16/P11 83204254 Black 10.4 16 75 260 5.6 50
EWT-PP-M20/P16 83204256 Black 13.9 20.6 85 295 8.8 50
EWT-PP-M25/P21 83204258 Black 20.6 28 130 455 12.2 50
EWT-PP-M32/P29 83204260 Black 25.6 34 140 490 16.5 25
EWT-PP-M40/P36 83204262 Black 31.8 43 160 560 26.6 25
EWT-PP-M50/P48 83204264 Black 42.5 53 170 595 32.2 25
EWT-PP-70 Jumbo 83261062 Black 60.5 78 190 655 44.0 10

Datasheet - PDF

▲
Title: Size: Type:
PDF CATALOG MURRPLASTIKS CONDUIT AND FITTING SYSTEMS EN.pdf 10 Mbytes
