8610100109 MURRPLASTIK Labelling Rectangular with radius Rectangular design with corner radius Matt red
8610100109
MURRPLASTIK
8
Labelling Rectangular with radius Rectangular design with corner radius Matt red
THE 54x14mm RT/M R2 SKS MS1.0
Rectangular with radius
Marking systems
Brand new product in its original packaging covered by the warranties and certifications provided by MURRPLASTIK
Best sellers
▲More info
▲The laser has served us well for years, especially for engraving and labelling of metals.
Marking anodised aluminium with the laser produces great contrast, durability, precision, great readability and can be done with great speed.
Optionally available with adhesive film (HF), self-adhesive film (SK) or self-adhesive film with foam adhesive (SKS)
Available in square versions with and without corner radius, in round versions (circular blanks), optionally with holes, slots or granulation
A suction and filter unit is absolutely necessary to comply with legal regulations on health protection.
-40°C – 140°C, short term 200°C
Aluminium anodised (ALU)
V0
| Type | Order No. | Colour | Material thickness mm | Printable area mm | No. characters/ lines | No. per Frame | Software Type | MOQ qty. | ||
|---|---|---|---|---|---|---|---|---|---|---|
Rectangular design with corner radius | ||||||||||
| LA 12x12 R2 SKS | 8610100253 | Black | 1 | 12 x 12 | 6.0 / 3.0 | 64 | NA0 | 256 | ||
| LA° 22x22 R2 SK | 8610100070 | Black | 1 | 22 x 22 | 12.0 / 6.0 | 16 | LV2 | 64 | ||
| LA 27x18 R2 SK | 8610100136 | Black | 1 | 27 x 18 | 15.0 / 5.0 | 15 | L5U | 60 | ||
| LA 27x27 R2 SK | 8610100067 | Black | 1 | 27 x 27 | 15.0 / 7.0 | 16 | LU9 | 64 | ||
| LA 30x15 R1 SK | 8610100254 | Black | 1 | 30 x 15 | 16.0 / 4.0 | 18 | NA8 | 72 | ||
| LA 30x60 R2 SK | 8610100172 | Black | 1 | 30 x 60 | 16.0 / 17.0 | 3 | L9F | 12 | ||
| LA 40x13 R2 SKS | 8610100207 | Black | 1 | 40 x 13 | 22.0 / 3.0 | 14 | MH1 | 56 | ||
| LA 40x80 R2 SK | 8610100170 | Black | 1 | 40 x 80 | 22.0 / 23.0 | 2 | L9D | 8 | ||
| LA 50x10 R2 SK | 8610100171 | Black | 1 | 50 x 10 | 27.0 / 2.0 | 18 | L9E | 72 | ||
| LA° 50x15 R2 SKS | 8610100034 | Black | 1 | 50 x 15 | 27.0 / 4.0 | 14 | LI4 | 56 | ||
| LA 80x25 R2 SKS | 8610100206 | Black | 1 | 80 x 25 | 44.0 / 7.0 | 4 | MH0 | 16 | ||
| LA° 100x50 R2 SKS | 8610100032 | Black | 1 | 100 x 50 | 55.0 / 14.0 | 2 | LI2 | 8 | ||
| LA 110X30 R4 SKS | 8610100040 | Black | 1 | 110 x 30 | 61.0 / 8.0 | 2 | LL8 | 12 | ||
| LA 22x22 R2 SK | 8610100163 | Silver | 1 | 22 x 22 | 12.0 / 6.0 | 16 | L8I | 64 | ||
| LA 27x27 R2 SK | 8610100164 | Silver | 1 | 27 x 27 | 15.0 / 7.0 | 9 | L8J | 36 | ||
| LA° 30x15 R2 SKS | 8610100029 | Silver | 1 | 30 x 15 | 16.0 / 4.0 | 21 | LH9 | 84 | ||
| LA° 40x80 R2 SK | 8610100036 | Silver | 1 | 40 x 80 | 22.0 / 23.0 | 2 | LI6 | 8 | ||
| LA 50x15 R2 SKS | 8610100035 | Silver | 1 | 50 x 15 | 27.0 / 4.0 | 14 | LI5 | 56 | ||
| LA 54x14 R2 SKS | 8610100110 | Silver | 1 | 54 x 14 | 30.0 / 4.0 | 14 | L3D | 56 | ||
| LA° 100x50 R2 SKS | 8610100031 | Silver | 1 | 100 x 50 | 55.0 / 14.0 | 2 | LI1 | 8 | ||
| LA° 100x100 R2 SKS | 8610100033 | Silver | 1 | 100 x 100 | 55.0 / 29.0 | 1 | LI3 | 4 | ||
| LA 120x50 R2 SKS | 8610100115 | Silver | 1 | 120 x 50 | 66.0 / 14.0 | 2 | L3I | 8 | ||
| LA 120x54 R2 HF | 8610100251 | Silver | 1 | 120 x 54 | 66.0 / 15.0 | 2 | MY4 | 8 | ||
| LA 120x54 R2 SK | 8610100154 | Silver | 1 | 120 x 54 | 66.0 / 15.0 | 2 | L7F | 8 | ||
| LA 120x80 R2 SKS | 8610100116 | Silver | 1 | 120 x 80 | 66.0 / 23.0 | 1 | L3J | 4 | ||
| LA 27x18 R2 SK | 8610100140 | Yellow matt | 1 | 27 x 18 | 15.0 / 5.0 | 15 | L5Y | 60 | ||
| LA 54x14 R2 SKS | 8610100108 | Yellow matt | 1 | 54 x 14 | 30.0 / 4.0 | 14 | L3B | 56 | ||
| LA 120x50 R2 SKS | 8610100111 | Yellow matt | 1 | 120 x 50 | 66.0 / 14.0 | 2 | L3E | 8 | ||
| LA 27x18 R2 SK | 8610100139 | Red glossy | 1 | 27 x 18 | 15.0 / 5.0 | 15 | L5X | 60 | ||
| LA 27x18 R2 SK | 8610100137 | Green glossy | 1 | 27 x 18 | 15.0 / 5.0 | 15 | L5V | 60 | ||
| LA 27x18 R2 SK | 8610100138 | Blue glossy | 1 | 27 x 18 | 15.0 / 5.0 | 15 | L5W | 60 | ||
| LA 54x14 R2 SKS | 8610100109 | Matt red | 1 | 54 x 14 | 30.0 / 4.0 | 14 | L3C | 56 | ||
| LA 100x35 R1 SKS | 8610100256 | Matt red | 1 | 100 x 35 | 55.0 / 10.0 | 3 | NB0 | 12 | ||
| LA 120x50 R2 SKS | 8610100114 | Matt red | 1 | 120 x 50 | 66.0 / 14.0 | 2 | L3H | 8 | ||
| LA 54x14 R2 SKS | 8610100118 | Green matt | 1 | 54 x 14 | 30.0 / 4.0 | 14 | L3L | 56 | ||
| LA 120x50 R2 SKS | 8610100113 | Green matt | 1 | 120 x 50 | 66.0 / 14.0 | 2 | L3G | 8 | ||
| LA 54x14 R2 SKS | 8610100117 | Blue matt | 1 | 54 x 14 | 30.0 / 4.0 | 14 | L3K | 56 | ||
| LA 120x50 R2 SKS | 8610100112 | Blue matt | 1 | 120 x 50 | 66.0 / 14.0 | 2 | L3F | 8 | ||
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOG MURRPLASTIKS LABELLING SYSTEMS EN.pdf | 8 Mbytes |
|
| 8610100109 8610100109 EN_8610100029.pdf | 741 Kbytes |
|
