8604246006 MURRPLASTIK Labelling Rectangular without radius, 4x hole Without corner radius with adhesive foi..
8604246006
MURRPLASTIK
20
Labelling Rectangular without radius, 4x hole Without corner radius; with adhesive foil Anodised silver
ALU 150x80 SI Elox HF, 4x4,0, MS1,0
ALU Rectangular without radius, 4x hole
Marking systems
Brand new product in its original packaging covered by the warranties and certifications provided by MURRPLASTIK
Best sellers
▲More info
▲The ALU labelling material, in mat size 300x200 mm, has been developed especially for engraving.
Coloured anodised aluminium material
Available with self-adhesive foil (SK) or with adhesive foil (HF).
Individual or prefab labels
Temperature range up to approx. 200 °C
Thickness: 1.0 mm
marking technique: Engraving
-40°C – 140°C
Aluminium anodised (ALU)
V0
| Type | Order No. | Label size mm | Number x Holes mm | Colour combination | Material thickness mm | No. per mat | Software type | MOQ qty. | ||
|---|---|---|---|---|---|---|---|---|---|---|
Without corner radius; with adhesive foil | ||||||||||
| ALU 30x70 HF, 4x3.0MM | 8604246002 | 70 x 30 | 4x 3.0 | Anodised black | 1 | 20 | 1L | 20 | ||
| ALU 80x50 HF, 4x3.5MM | 8604246007 | 80 x 50 | 4x 3.5 | Anodised black | 1 | 12 | G48 | 12 | ||
| ALU 60x20 HF, 4x3.5MM | 8604946000 | 60 x 20 | 4x 3.5 | Anodised silver | 1 | 50 | 057 | 50 | ||
| ALU 60x30 HF, 4x5.0MM | 8604246001 | 60 x 30 | 4x 5.0 | Anodised silver | 1 | 30 | 888 | 30 | ||
| ALU 85x180 HF, 4x3.4MM | 8604246009 | 85 x 180 | 4x 3.4 | Anodised silver | 1 | 3 | K24 | 3 | ||
| ALU 90x45 HF, 4x3.2MM | 8604246003 | 90 x 45 | 4x 3.2 | Anodised silver | 1 | 12 | 3U | 12 | ||
| ALU 100x75 HF, 4x2.6MM | 8604246000 | 100 x 75 | 4x 2.6 | Anodised silver | 1 | 6 | 656 | 6 | ||
| ALU 100x155 HF, 4x2.5MM | 8604246004 | 100 x 155 | 4x 2.5 | Anodised silver | 1 | 3 | 5V | 3 | ||
| ALU 140x100 HF, 4x2.5MM | 8604246005 | 140 x 100 | 4x 2.5 | Anodised silver | 1 | 4 | 5W | 4 | ||
| ALU 150x80 HF, 4x4.0MM | 8604246006 | 150 x 80 | 4x 4.0 | Anodised silver | 1 | 4 | 8W | 4 | ||
| ALU 90x45 HF, 4x3.2MM | 8604246011 | 90 x 45 | 4x 3.2 | Anodised Blue | 1 | 12 | Z84 | 12 | ||
Without corner radius; with self-adhesive foil | ||||||||||
| ALU 90x45 SK, 4x3,0MM | 8604240003 | 90 x 45 | 4x 3.0 | Anodised black | 1 | 12 | Z63 | 12 | ||
| ALU 70x100 SK, 4x3.2MM | 8604240002 | 100 x 70 | 4x 3.2 | Anodised silver | 1 | 8 | 226 | 8 | ||
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOG MURRPLASTIKS LABELLING SYSTEMS EN.pdf | 8 Mbytes |
|
| 8604246006 8604246006 EN_8604240002.pdf | 847 Kbytes |
|
