8604220004 MURRPLASTIK Labelling Rectangular without radius, 2x hole Without corner radius with self-adhesiv..
8604220004
MURRPLASTIK
900
Labelling Rectangular without radius, 2x hole Without corner radius; with self-adhesive foil Anodised silver
ALU 25x10 SI Elox SK, 2x2,2 MS1,0
Rectangular without radius, 2x hole
Marking systems
Brand new product in its original packaging covered by the warranties and certifications provided by MURRPLASTIK
Best sellers
▲More info
▲The ALU labelling material, in mat size 300x200 mm, has been developed especially for engraving.
Coloured anodised aluminium material
Available with self-adhesive foil (SK) or with adhesive foil (HF).
Individual or prefab labels
Temperature range up to approx. 200 °C
Thickness: 1.0 mm
marking technique: Engraving
-40°C – 140°C
Aluminium anodised (ALU)
V0
| Type | Order No. | Label size mm | Number x Holes mm | Colour combination | Material thickness mm | No. per mat | Software type | MOQ qty. | ||
|---|---|---|---|---|---|---|---|---|---|---|
Without corner radius; with adhesive foil | ||||||||||
| ALU 10x40 HF, 2x2.5MM | 8604226046 | 10 x 40 | 2x 2.5 | Anodised silver | 1 | 150 | M62 | 150 | ||
| ALU 15x40 HF, 2x3.0MM | 8604226042 | 15 x 40 | 2x 3.0 | Anodised silver | 1 | 100 | H54 | 100 | ||
| ALU 26x80 HF, 2x2.5MM | 8604226045 | 26 x 80 | 2x 2.5 | Anodised silver | 1 | 22 | M55 | 22 | ||
| ALU 30x10 HF, 2x2.5MM (X=24) | 8604226009 | 30 x 10 | 2x 2.5 | Anodised silver | 1 | 200 | 868 | 200 | ||
| ALU 30x10 HF, 2x2.5MM (X=26) | 8604226021 | 30 x 10 | 2x 2.5 | Anodised silver | 1 | 200 | 178 | 200 | ||
| ALU 30x30 HF, 2x5.0MM | 8604226047 | 30 x 30 | 2x 5.0 | Anodised silver | 1 | 60 | M75 | 60 | ||
| ALU 34x12 HF, 2x3.5MM | 8604226023 | 34 x 12 | 2x 3.5 | Anodised silver | 1 | 128 | 617 | 128 | ||
| ALU 37x18 HF, 2x3.2MM | 8604226010 | 37 x 18 | 2x 3.2 | Anodised silver | 1 | 88 | 925 | 88 | ||
| ALU° 40x15 HF, 2x2.5MM | 8604226000 | 40 x 15 | 2x 2.5 | Anodised silver | 1 | 91 | 484 | 91 | ||
| ALU 40x20 HF, 2x3.0MM | 8604226027 | 40 x 20 | 2x 3.0 | Anodised silver | 1 | 70 | 4M | 70 | ||
| ALU 40x20 HF, 2x3.2MM | 8604226020 | 40 x 20 | 2x 3.2 | Anodised silver | 1 | 70 | 137 | 70 | ||
| ALU 45x19 HF, 2x2.6MM | 8604226025 | 45 x 19 | 2x 2.6 | Anodised silver | 1 | 60 | 1H | 60 | ||
| ALU 50x20 HF, 2x3.3MM | 8604226039 | 50 x 20 | 2x 3.3 | Anodised silver | 1 | 54 | D17 | 60 | ||
| ALU° 55x20 HF, 2x2.5MM | 8604226001 | 55 x 20 | 2x 2.5 | Anodised silver | 1 | 50 | 482 | 50 | ||
| ALU 55x25 HF, 2x4.0MM | 8604226022 | 55 x 25 | 2x 4.0 | Anodised silver | 1 | 40 | 213 | 40 | ||
| ALU 60X15 HF, 2x3.4MM | 8604226044 | 60 x 15 | 2x 3.4 | Anodised silver | 1 | 65 | K25 | 65 | ||
| ALU 60x25 HF, 2x3.0MM | 8604226018 | 60 x 25 | 2x 3.0 | Anodised silver | 1 | 10 | 385 | 40 | ||
| ALU 60x30 HF, 2x3.3MM | 8604226036 | 60 x 30 | 2x 3.3 | Anodised silver | 1 | 30 | D14 | 30 | ||
| ALU 70x10 HF, 2x2.0MM | 8604226007 | 70 x 10 | 2x 2.0 | Anodised silver | 1 | 80 | 766 | 80 | ||
| ALU 70x26 HF, 2x3.3MM | 8604226038 | 70 x 26 | 2x 3.3 | Anodised silver | 1 | 28 | D16 | 28 | ||
| ALU 70x27 HF, 2x2.6MM | 8604226024 | 70 x 27 | 2x 2.6 | Anodised silver | 1 | 28 | 655 | 28 | ||
| ALU 70x50 HF, 2x3.3MM | 8604226037 | 70 x 50 | 2x 3.3 | Anodised silver | 1 | 16 | D15 | 16 | ||
| ALU 74x26 HF, 2x3.2MM | 8604226016 | 74 x 26 | 2x 3.2 | Anodised silver | 1 | 28 | 360 | 28 | ||
| ALU 100x40 HF, 2x2.5MM | 8604226019 | 100 x 40 | 2x 2.5 | Anodised silver | 1 | 15 | R3A | 15 | ||
| ALU 105x37 HF, 2x3.2MM | 8604226017 | 105 x 37 | 2x 3.2 | Anodised silver | 1 | 10 | 654 | 10 | ||
| ALU 145x85 HF, 2x2.6MM (diagonal) | 8604226026 | 145 x 85 | 2x 2.6 | Anodised silver | 1 | 4 | 3J | 4 | ||
| ALU 290x30 HF, 2x3.0MM | 8604216001 | 290 x 30 | 2x 3.0 | Anodised silver | 1 | 6 | 780 | 6 | ||
| ALU 15x80 HF, 2x2.5MM | 8604226013 | 15 x 80 | 2x 2.5 | Anodised black | 1 | 39 | 665 | 40 | ||
| ALU 30x10 HF, 2x3.2MM | 8604226011 | 30 x 10 | 2x 3.2 | Anodised black | 1 | 200 | 934 | 200 | ||
| ALU 40x10 HF, 2x4.0MM | 8604226015 | 40 x 10 | 2x 4.0 | Anodised black | 1 | 140 | 240 | 140 | ||
| ALU 40x12 HF, 2x2.2MM | 8604226035 | 40 x 12 | 2x 2.2 | Anodised black | 1 | 112 | D11 | 112 | ||
| ALU 40x15 HF, 2x2.5MM | 8604226012 | 40 x 15 | 2x 2.5 | Anodised black | 1 | 91 | 409 | 91 | ||
| ALU 40x15 HF, 2x3.3MM | 8604226040 | 40 x 15 | 2x 3.3 | Anodised black | 1 | 91 | D18 | 91 | ||
| ALU 40x20 HF, 2x3.0MM | 8604226008 | 40 x 20 | 2x 3.0 | Anodised black | 1 | 70 | 777 | 70 | ||
| ALU 40x24 HF, 2x2.2MM | 8604226034 | 40 x 24 | 2x 2.2 | Anodised black | 1 | 56 | D10 | 56 | ||
| ALU 50x20 HF, 2x3.5MM | 8604226030 | 50 x 20 | 2x 3.5 | Anodised black | 1 | 60 | 78 | 60 | ||
| ALU° 55x20 HF, 2x2.5MM | 8604226006 | 55 x 20 | 2x 2.5 | Anodised black | 1 | 50 | 748 | 50 | ||
| ALU 60x20 HF, 2x3.5MM | 8604226028 | 60 x 20 | 2x 3.5 | Anodised black | 1 | 50 | 5H | 50 | ||
| ALU 70x25 HF, 2x3.5MM | 8604226032 | 70 x 25 | 2x 3.5 | Anodised black | 1 | 32 | 7I | 32 | ||
| ALU 25x65 HF, 2x4.0MM | 8604226048 | 25 x 65 | 2x 4.0 | Anodised red | 1 | 36 | M91 | 216 | ||
| ALU 60x40 HF, 2x2.0MM | 8604226031 | 60 x 40 | 2x 2.0 | Anodised red | 1 | 25 | 6M | 25 | ||
| ALU 120x80 HF, 2x6.0MM | 8604226043 | 120 x 80 | 2x 6.0 | Anodised red | 1 | 4 | H76 | 4 | ||
| ALU 36x10 HF, 2x2.5MM | 8604226041 | 36 x 10 | 2x 2.5 | Anodised Blue | 1 | 160 | D42 | 160 | ||
| ALU 60x20 HF, 2x3.5MM | 8604226029 | 60 x 20 | 2x 3.5 | Anodised Blue | 1 | 50 | 5I | 50 | ||
Without corner radius; with self-adhesive foil | ||||||||||
| ALU 18x200 SK, 2x3.0MM | 8604220014 | 18 x 200 | 2x 3.0 | Anodised silver | 1 | 16 | 2J | 16 | ||
| ALU 25x10 SK, 2x2.2MM | 8604220004 | 25 x 10 | 2x 2.2 | Anodised silver | 1 | 240 | 367 | 240 | ||
| ALU 30x15 SK, 2x2.5MM | 8604220011 | 30 x 15 | 2x 2.5 | Anodised silver | 1 | 130 | 688 | 130 | ||
| ALU 40x9 SK, 2x2.5MM | 8604220001 | 40 x 9 | 2x 2.5 | Anodised silver | 1 | 154 | 988 | 154 | ||
| ALU 50x12.5 SK, 2x3.0MM | 8604220002 | 50 x 12.5 | 2x 3.0 | Anodised silver | 1 | 96 | 050 | 96 | ||
| ALU 50x25 SK, 2x3.0MM | 8604220003 | 50 x 25 | 2x 3.0 | Anodised silver | 1 | 48 | 027 | 48 | ||
| ALU 50x25 SK, 2x3,0MM | 8604220015 | 50 x 25 | 2x 3.0 | Anodised silver | 1 | 48 | Z76 | 48 | ||
| ALU 60x16 SK, 2x2.5MM | 8604220007 | 60 x 16 | 2x 2.5 | Anodised silver | 1 | 60 | 193 | 60 | ||
| ALU 90x16 SK, 2x2.5MM | 8604220005 | 90 x 16 | 2x 2.5 | Anodised silver | 1 | 36 | 190 | 36 | ||
| ALU 130x32 SK, 2x2.5MM | 8604220013 | 130 x 32 | 2x 2.5 | Anodised silver | 1 | 12 | 689 | 12 | ||
| ALU 180x32 SK, 2x2.5MM | 8604220008 | 180 x 32 | 2x 2.5 | Anodised silver | 1 | 6 | 194 | 6 | ||
| ALU 230x32 SK, 2x2.5MM | 8604220006 | 230 x 32 | 2x 2.5 | Anodised silver | 1 | 6 | 191 | 6 | ||
| ALU 25x10 SK, 2x2.2MM | 8604220009 | 25 x 10 | 2x 2.2 | Anodised black | 1 | 240 | 515 | 240 | ||
| ALU 70x10 SK, 2x2.2MM | 8604220010 | 70 x 10 | 2x 2.2 | Anodised black | 1 | 80 | 536 | 80 | ||
| ALU 30x15 SK, 2x2.3MM | 8604220000 | 30 x 15 | 2x 2.3 | Anodised Blue | 1 | 130 | 860 | 130 | ||
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOG MURRPLASTIKS LABELLING SYSTEMS EN.pdf | 8 Mbytes |
|
| 8604220004 8604220004 EN_8604216001.pdf | 997 Kbytes |
|
