8604200002 MURRPLASTIK Labelling Rectangular without radius Without corner radius with self-adhesive foil An..
8604200002
MURRPLASTIK
144
Labelling Rectangular without radius Without corner radius; with self-adhesive foil Anodised silver
ALU 15x200 SI Elox SK, MS1,0
Rectangular without radius
Marking systems
Brand new product in its original packaging covered by the warranties and certifications provided by MURRPLASTIK
Best sellers
▲More info
▲The ALU labelling material, in mat size 300x200 mm, has been developed especially for engraving.
Coloured anodised aluminium material
Available with self-adhesive foil (SK) or with adhesive foil (HF).
Individual or prefab labels
Temperature range up to approx. 200 °C
Thickness: 1.0 mm
marking technique: Engraving
-40°C – 140°C
Aluminium anodised (ALU)
V0
| Type | Order No. | Label size mm | Colour combination | Material thickness mm | No. per mat | Software type | MOQ qty. | ||
|---|---|---|---|---|---|---|---|---|---|
Without corner radius; with self-adhesive foil | |||||||||
| ALU 15x200 SK | 8604200002 | 15 x 200 | Anodised silver | 1 | 20 | 2K | 20 | ||
| ALU 40x20 SK | 8604200006 | 40 x 20 | Anodised silver | 1 | 70 | A29 | 70 | ||
| ALU 47x47 SK | 8604200004 | 47 x 47 | Anodised silver | 1 | 24 | 5D | 24 | ||
| ALU 70x35 SK | 8604200003 | 70 x 35 | Anodised silver | 1 | 20 | 3R | 20 | ||
| ALU 75x25 SK | 8604200001 | 75 x 25 | Anodised silver | 1 | 32 | 69 | 32 | ||
| ALU 20x40 SK | 8604200008 | 20 x 40 | Anodised black | 1 | 75 | A1B | 75 | ||
| ALU 29x8 SK | 8604206013 | 29 x 8 | Anodised black | 1 | 250 | 3Q | 250 | ||
| ALU 80x55 SK | 8604200005 | 80 x 55 | Anodised black | 1 | 9 | 5F | 9 | ||
| ALU 100x50 SK | 8604200007 | 100 x 50 | Anodised Blue | 1 | 12 | D46 | 12 | ||
Without corner radius; with adhesive foil | |||||||||
| ALU 25x10 HF | 8604206007 | 25 x 10 | Anodised silver | 1 | 240 | 295 | 240 | ||
| ALU 29x9 HF | 8604206011 | 29 x 9 | Anodised silver | 1 | 220 | 2O | 220 | ||
| ALU 30x20 HF | 8604206006 | 30 x 20 | Anodised silver | 1 | 100 | 280 | 100 | ||
| ALU 52x21 HF | 8604206016 | 52 x 21 | Anodised silver | 1 | 45 | A32 | 45 | ||
| ALU 80x10 HF | 8604206026 | 80 x 10 | Anodised silver | 1 | 60 | K81 | 60 | ||
| ALU 80x30 HF | 8604206015 | 80 x 30 | Anodised silver | 1 | 18 | 4W | 18 | ||
| ALU 80x49 HF | 8604206022 | 80 x 49 | Anodised silver | 1 | 12 | J35 | 12 | ||
| ALU 101.6x152.4 HF | 8604206019 | 101.6 x 152.4 | Anodised silver | 1 | 2 | G36 | 2 | ||
| ALU 120x20 HF | 8604206025 | 120 x 20 | Anodised silver | 1 | 20 | K75 | 20 | ||
| ALU 120x50 HF | 8604206027 | 120 x 50 | Anodised silver | 1 | 8 | L99 | 8 | ||
| ALU 150x200 HF | 8604206024 | 150 x 200 | Anodised silver | 1 | 2 | K26 | 2 | ||
| ALU 297x420 HF | 8604206020 | 297 x 420 | Anodised silver | 1 | 1 | I85 | 1 | ||
| ALU 300x200 HF (E) | 8604206005 | 300 x 200 | Anodised silver | 1 | 1 | AL1 | 1 | ||
| ALU 25x10 HF | 8604206014 | 25 x 10 | Anodised black | 1 | 240 | 3Z | 240 | ||
| ALU 25x16 HF | 8604206021 | 25 x 16 | Anodised black | 1 | 144 | J14 | 144 | ||
| ALU 29x8 HF | 8604206012 | 29 x 8 | Anodised black | 1 | 250 | 3P | 250 | ||
| ALU 40x170 HF | 8604206010 | 40 x 170 | Anodised black | 1 | 7 | 2l | 7 | ||
| ALU 45x25 HF | 8604206008 | 45 x 25 | Anodised black | 1 | 48 | 841 | 48 | ||
| ALU 100x40 HF | 8604206018 | 100 x 40 | Anodised black | 1 | 15 | D04 | 15 | ||
| ALU 100x100 HF | 8604206017 | 100 x 100 | Anodised black | 1 | 6 | D03 | 6 | ||
| ALU 140x40 HF | 8604206009 | 140 x 40 | Anodised black | 1 | 10 | 2H | 10 | ||
| ALU 260x40 HF | 8604206004 | 260 x 40 | Anodised black | 1 | 5 | 905 | 5 | ||
| ALU 300x200 HF (E) | 8604206002 | 300 x 200 | Anodised black | 1 | 1 | AL1 | 1 | ||
| ALU 300x200 HF (E) | 8604206023 | 300 x 200 | Silver / Black | 1 | 1 | AL1 | 1 | ||
Without corner radius; with high-strength adhesive foam foil | |||||||||
| ALU 40x40 SKS | 8604202002 | 40 x 40 | Anodised silver | 1 | 35 | K83 | 35 | ||
| ALU 26.5x18 SKS | 8604202001 | 26.5 x 18 | Anodised black | 1 | 121 | K27 | 121 | ||
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOG MURRPLASTIKS LABELLING SYSTEMS EN.pdf | 8 Mbytes |
|
| 8604200002 8604200002 EN_8604206015.pdf | 773 Kbytes |
|
