8604140002 MURRPLASTIK Labelling Rectangular with radius, 4x hole Corner radius 2 mm with self-adhesive foil..
Reference: 8604140002
Manufacturer: MURRPLASTIK
Description:
Labelling Rectangular with radius, 4x hole Corner radius 2 mm; with self-adhesive foil Anodised silver
ALU 40x15 SI Elox R SK, 4x3, MS1,0
ALU Rectangular with radius, 4x hole
Categories:
- MURRPLASTIK > Marking systems
Brand new product in its original packaging covered by the warranties and certifications provided by MURRPLASTIK
- More Info
- Reviews
LAST VIEWED
MORE INFO
The ALU labelling material, in mat size 300x200 mm, has been developed especially for engraving.
Coloured anodised aluminium material
Available with self-adhesive foil (SK) or with adhesive foil (HF).
Individual or prefab labels
Temperature range up to approx. 200 °C
Thickness: 1.0 mm
marking technique: Engraving
-40°C – 140°C
Aluminium anodised (ALU)
V0
| Type | Order No. | Label size mm | Number x Holes mm | Colour combination | Material thickness mm | No. per mat | Software type | MOQ qty. | ||
|---|---|---|---|---|---|---|---|---|---|---|
Corner radius 2 mm; with adhesive foil | ||||||||||
| ALU 15x80 R2 HF, 4x3.5MM | 8604146015 | 15 x 80 | 4x 3.5 | Anodised silver | 1 | 40 | M24 | 40 | ||
| ALU 40x15 R2 HF, 4x3.0MM | 8604146006 | 40 x 15 | 4x 3.0 | Anodised silver | 1 | 91 | A6 | 91 | ||
| ALU 45x30 R2 HF, 4x4.0MM | 8604146007 | 45 x 30 | 4x 4.0 | Anodised silver | 1 | 36 | A33 | 36 | ||
| ALU 50x45 R2 HF, 4x2.2MM | 8604144000 | 50 x 45 | 4x 2.2 | Anodised silver | 1 | 24 | 706 | 24 | ||
| ALU 60x15 R2 HF, 4x3.0MM | 8604146005 | 60 x 15 | 4x 3.0 | Anodised silver | 1 | 65 | A5 | 65 | ||
| ALU 70x12 R2 HF, 4x3,1MM | 8604146016 | 70 x 12 | 4x 3.1 | Anodised silver | 1 | 64 | Z59 | 64 | ||
| ALU 80x200 R2 HF, 4x3.4MM | 8604146012 | 80 x 200 | 4x 3.4 | Anodised silver | 1 | 3 | K23 | 3 | ||
| ALU 85x25 R2 HF, 4x2.2MM | 8604144001 | 85 x 25 | 4x 2.2 | Anodised silver | 1 | 24 | 705 | 24 | ||
| ALU 140x90 R2 HF, 4x2.5MM | 8604146003 | 140 x 90 | 4x 2.5 | Anodised silver | 1 | 4 | 645 | 4 | ||
| ALU 140x90 R2 HF, 4x3.2MM | 8604146004 | 140 x 90 | 4x 3.2 | Anodised silver | 1 | 4 | A1 | 4 | ||
| ALU 40x15 R2 HF, 4x2.5MM | 8604146001 | 40 x 15 | 4x 2.5 | Anodised black | 1 | 91 | 392 | 91 | ||
| ALU 60x12 R2 HF, 4x2.0MM | 8604146009 | 60 x 12 | 4x 2.0 | Anodised black | 1 | 80 | G49 | 80 | ||
| ALU 60x25 R2 HF, 4x3.0MM | 8604146008 | 60 x 25 | 4x 3.0 | Anodised black | 1 | 24 | B28 | 6 | ||
| ALU 80x80 R2 HF, 4x3,3MM | 8604146017 | 80 x 80 | 4x 3.3 | Anodised black | 1 | 6 | A8B | 6 | ||
Corner radius 2 mm; with self-adhesive foil | ||||||||||
| ALU 40x15 R2 SK, 4x3.0MM | 8604140002 | 40 x 15 | 4x 3.0 | Anodised silver | 1 | 91 | 987 | 91 | ||
| ALU 60x15 R2 SK, 4x3.0MM | 8604140001 | 60 x 15 | 4x 3.0 | Anodised silver | 1 | 65 | 986 | 65 | ||
| ALU 70x12 R2 SK, 4x3.1MM | 8604140003 | 70 x 12 | 4x 3.1 | Anodised silver | 1 | 64 | H93 | 64 | ||
| ALU 100x70 R2 SK, 4x4.0MM | 8604140000 | 100 x 70 | 4x 4.0 | Anodised silver | 1 | 6 | 859 | 6 | ||
| ALU 120x100 R2 SK, 4x2.5MM | 8604140004 | 120 x 100 | 4x 2.5 | Anodised Blue | 1 | 4 | M67 | 4 | ||
Corner radius 1 mm; with self-adhesive foil | ||||||||||
| ALU 70x45 R1 SK, 4x3.2MM | 8604140039 | 70 x 45 | 4x 3.2 | Anodised silver | 1 | 16 | H80 | 16 | ||
Corner radius 3 mm; with adhesive foil | ||||||||||
| ALU 60x100 R3 HF, 4x3.5MM | 8604146014 | 60 x 100 | 4x 3.5 | Anodised black | 1 | 10 | K72 | 10 | ||
