8604120002 MURRPLASTIK Labelling Rectangular with radius, 2x hole Corner radius 2 mm with self-adhesive foil..
8604120002
MURRPLASTIK
250
Labelling Rectangular with radius, 2x hole Corner radius 2 mm; with self-adhesive foil Anodised black
ALU 30x8 SW Elox R SK, 2x2,5, MS1,0
ALU Rectangular with radius, 2x hole
Marking systems
Brand new product in its original packaging covered by the warranties and certifications provided by MURRPLASTIK
Best sellers
▲More info
▲The ALU labelling material, in mat size 300x200 mm, has been developed especially for engraving.
Coloured anodised aluminium material
Available with self-adhesive foil (SK) or with adhesive foil (HF).
Individual or prefab labels
Temperature range up to approx. 200 °C
Thickness: 1.0 mm
marking technique: Engraving
-40°C – 140°C
Aluminium anodised (ALU)
V0
| Type | Order No. | Label size mm | Number x Holes mm | Colour combination | Material thickness mm | No. per mat | Software type | MOQ qty. | ||
|---|---|---|---|---|---|---|---|---|---|---|
Corner radius 2 mm; with adhesive foil | ||||||||||
| ALU 15x50 R2 HF, 2x3.2MM | 8604126046 | 15 x 50 | 2x 3.2 | Anodised silver | 1 | 80 | M27 | 80 | ||
| ALU 15x50 R2 HF, 2x4.2MM | 8604126044 | 15 x 50 | 2x 4.2 | Anodised silver | 1 | 80 | L50 | 80 | ||
| ALU 15x80 R2 HF, 2x4.2MM | 8604126045 | 15 x 80 | 2x 4.2 | Anodised silver | 1 | 40 | L51 | 40 | ||
| ALU° 30x8 R2 HF, 2x2.5MM | 8604126000 | 30 x 8 | 2x 2.5 | Anodised silver | 1 | 250 | 202 | 250 | ||
| ALU 30x10 R2 HF, 2x3.5MM | 8604126039 | 30 x 10 | 2x 3.5 | Anodised silver | 1 | 200 | I59 | 200 | ||
| ALU° 30x15 R2 HF, 2x2.2MM | 8604126001 | 30 x 15 | 2x 2.2 | Anodised silver | 1 | 130 | 361 | 130 | ||
| ALU 30x15 R2 HF, 2x3.5MM | 8604126017 | 30 x 15 | 2x 3.5 | Anodised silver | 1 | 130 | 312 | 130 | ||
| ALU° 30x15 R2 HF, 2x4.0MM | 8604126005 | 30 x 15 | 2x 4.0 | Anodised silver | 1 | 130 | 362 | 130 | ||
| ALU 30x15 R2 HF 2x4.2MM | 8604126043 | 30 x 15 | 2x 4.2 | Anodised silver | 1 | 130 | L49 | 130 | ||
| ALU 36x10 R2 HF, 2x2,5MM | 8604126048 | 36 x 10 | 2x 2.5 | Anodised silver | 1 | 160 | Z64 | 160 | ||
| ALU 36x10 R2 HF, 2x2,5MM | 8604126049 | 36 x 10 | 2x 2.5 | Anodised silver | 1 | 160 | Z82 | 160 | ||
| ALU 40x10 R2 HF, 2x4.0MM | 8604126009 | 40 x 10 | 2x 4.0 | Anodised silver | 1 | 140 | 871 | 140 | ||
| ALU° 40x12 R2 HF, 2x2.5MM | 8604126007 | 40 x 12 | 2x 2.5 | Anodised silver | 1 | 112 | 283 | 112 | ||
| ALU 40x15 R2 HF, 2x3.0MM | 8604126024 | 40 x 15 | 2x 3.0 | Anodised silver | 1 | 91 | 153 | 91 | ||
| ALU° 40x15 R2 HF, 2x4.0MM | 8604226003 | 40 x 15 | 2x 4.0 | Anodised silver | 1 | 91 | 732 | 91 | ||
| ALU 40x25 R2 HF, 2x3.0MM | 8604126014 | 40 x 25 | 2x 3.0 | Anodised silver | 1 | 56 | 394 | 56 | ||
| ALU 42x16 R2 HF, 2x3.2MM | 8604126029 | 42 x 16 | 2x 3.2 | Anodised silver | 1 | 84 | 4E | 84 | ||
| ALU 45x10 R2 HF, 2x2.5MM | 8604126012 | 45 x 10 | 2x 2.5 | Anodised silver | 1 | 120 | 884 | 120 | ||
| ALU 45x18 R2 HF, 2x2.5MM | 8604126032 | 45 x 18 | 2x 2.5 | Anodised silver | 1 | 66 | 396 | |||
| ALU 50x15 R2 HF, 2x3.2MM | 8604126028 | 50 x 15 | 2x 3.2 | Anodised silver | 1 | 78 | 4C | 78 | ||
| ALU° 50x15 R2 HF, 2x3.5MM | 8604126022 | 50 x 15 | 2x 3.5 | Anodised silver | 1 | 78 | 064 | 78 | ||
| ALU 50x15 R2 HF, 2x3.5MM | 8604126027 | 50 x 15 | 2x 3.5 | Anodised silver | 1 | 78 | 4A | 78 | ||
| ALU 50x30 R2 HF, 2x2.2MM | 8604126021 | 50 x 30 | 2x 2.2 | Anodised silver | 1 | 36 | 063 | 36 | ||
| ALU 50x30 R2 HF, 2x3.0MM | 8604226005 | 50 x 30 | 2x 3.0 | Anodised silver | 1 | 36 | 737 | 36 | ||
| ALU 50x40 R2 HF, 2x3.0MM | 8604226004 | 50 x 40 | 2x 3.0 | Anodised silver | 1 | 30 | 738 | 30 | ||
| ALU° 52x18 R2 HF, 2x2.5MM | 8604126006 | 52 x 18 | 2x 2.5 | Anodised silver | 1 | 55 | RI0 | 55 | ||
| ALU 52x18 R2 HF, 2x3.2MM | 8604126030 | 52 x 18 | 2x 3.2 | Anodised silver | 1 | 55 | 4G | 55 | ||
| ALU 58x23 R2 HF, 2x4,0MM | 8604126053 | 58 x 23 | 2x 4.0 | Anodised silver | 1 | 40 | A4F | 40 | ||
| ALU 60x40 R2 HF, 2x2.5MM | 8604126016 | 60 x 40 | 2x 2.5 | Anodised silver | 1 | 25 | 42 | 25 | ||
| ALU 74x10 R2 HF, 2x2.5MM | 8604126013 | 74 x 10 | 2x 2.5 | Anodised silver | 1 | 80 | 883 | 80 | ||
| ALU 80x15 R2 HF, 2x4.0MM | 8604126008 | 80 x 15 | 2x 4.0 | Anodised silver | 1 | 39 | 787 | 39 | ||
| ALU 100x50 R2 HF, 2x2.5MM | 8604126015 | 100 x 50 | 2x 2.5 | Anodised silver | 1 | 12 | 364 | 12 | ||
| ALU 125x40 R2 HF, 2x2.5MM | 8604226002 | 125 x 40 | 2x 2.5 | Anodised silver | 1 | 10 | 676 | 10 | ||
| ALU 15x100 R2 HF, 2x3,3MM | 8604126050 | 15 x 100 | 2x 3.3 | Anodised black | 1 | 40 | A9B | 40 | ||
| ALU° 30x8 R2 HF, 2x2.5MM | 8604126004 | 30 x 8 | 2x 2.5 | Anodised black | 1 | 250 | 485 | 250 | ||
| ALU° 30x15 R2 HF, 2x2.2MM | 8604126002 | 30 x 15 | 2x 2.2 | Anodised black | 1 | 130 | 466 | 130 | ||
| ALU° 30x15 R2 HF, 2x4.0MM | 8604126003 | 30 x 15 | 2x 4.0 | Anodised black | 1 | 130 | 463 | 130 | ||
| ALU 36x10 R2 HF, 2x2.5MM | 8604126019 | 36 x 10 | 2x 2.5 | Anodised black | 1 | 160 | 013 | 160 | ||
| ALU 36x10 R2 HF, 2x4.0MM | 8604126018 | 36 x 10 | 2x 4.0 | Anodised black | 1 | 160 | 531 | 160 | ||
| ALU 45x10 R2 HF, 2x2.5MM | 8604126010 | 45 x 10 | 2x 2.5 | Anodised black | 1 | 120 | 885 | 120 | ||
| ALU 45x10 R2 HF, 2x3.0MM | 8604126035 | 45 x 10 | 2x 3.0 | Anodised black | 1 | 120 | E27 | 120 | ||
| ALU 52x18 R2 HF, 2x2.5MM | 8604126025 | 52 x 18 | 2x 2.5 | Anodised black | 1 | 55 | 618 | 55 | ||
| ALU 52x26 R2 HF, 2x2.5MM | 8604126026 | 52 x 26 | 2x 2.5 | Anodised black | 1 | 35 | 619 | 35 | ||
| ALU 60x12 R2 HF, 2x2.5MM | 8604126037 | 60 x 12 | 2x 2.5 | Anodised black | 1 | 80 | H92 | 80 | ||
| ALU 60x40 R2 HF, 2x2.5MM | 8604126020 | 60 x 40 | 2x 2.5 | Anodised black | 1 | 25 | 67 | 25 | ||
| ALU 74x10 R2 HF, 2x2.5MM | 8604126011 | 74 x 10 | 2x 2.5 | Anodised black | 1 | 80 | 882 | 80 | ||
| ALU 74x18 R2 HF 2x3,1MM | 8604126040 | 74 x 18 | 2x 3.1 | Anodised black | 1 | 44 | K63 | 44 | ||
| ALU 60x20 R2 HF, 2x3.5MM | 8604126041 | 60 x 20 | 2x 3.5 | Anodised red | 1 | 50 | K71 | 50 | ||
| ALU 70x30 R2 HF, 2x3,5MM | 8604126052 | 70 x 30 | 2x 3.5 | Anodised red | 1 | 24 | A5E | 24 | ||
| ALU 100x50 R2 HF, 2x3.1MM | 8604126033 | 100 x 50 | 2x 3.1 | Anodised red | 1 | 12 | 6J | 12 | ||
| ALU 70x30 R2 HF, 2x3.5MM | 8604126042 | 70 x 30 | 2x 3.5 | Gold anodized | 1 | 24 | K78 | 24 | ||
| ALU 70x30 R2 HF, 2x3,5MM | 8604126051 | 70 x 30 | 2x 3.5 | Anodised Blue | 1 | 24 | A4E | 24 | ||
Corner radius 1 mm; with adhesive foil | ||||||||||
| ALU 25x10 R1 HF, 2x3.2MM | 8604126036 | 25 x 10 | 2x 3.2 | Anodised silver | 1 | 240 | H77 | 240 | ||
| ALU 25x8 R1 HF, 2x3,2MM | 8604126047 | 25 x 8 | 2x 3.2 | Anodised black | 1 | 300 | M69 | 300 | ||
Corner radius 2 mm; with self-adhesive foil | ||||||||||
| ALU 30x15 R2 SK, 2x2.2MM | 8604120005 | 30 x 15 | 2x 2.2 | Anodised silver | 1 | 130 | 9P | 130 | ||
| ALU 30x15 R2 SK, 2x4.0MM | 8604120001 | 30 x 15 | 2x 4.0 | Anodised silver | 1 | 130 | 060 | 130 | ||
| ALU 30x8 R2 SK, 2x2.5MM | 8604120002 | 30 x 8 | 2x 2.5 | Anodised black | 1 | 250 | 230 | 250 | ||
| ALU 30x20 R2 SK, 2x2.2MM | 8604120006 | 30 x 20 | 2x 2.2 | Anodised black | 1 | 100 | J37 | 100 | ||
Corner radius 6 mm; with adhesive foil | ||||||||||
| ALU 40x12 R6 HF, 2x3.5MM | 8604126023 | 40 x 12 | 2x 3.5 | Anodised silver | 1 | 112 | 067 | 112 | ||
Corner radius 3 mm; with adhesive foil | ||||||||||
| ALU 52x18 R3 HF, 2x3.2MM | 8604126038 | 52 x 18 | 2x 3.2 | Anodised silver | 1 | 55 | I56 | 55 | ||
Corner radius 1 mm; with self-adhesive foil | ||||||||||
| ALU 60x15 R1 SK, 2x3.2MM | 8604120037 | 60 x 15 | 2x 3.2 | Anodised silver | 1 | 65 | H78 | 65 | ||
| ALU 70x15 R1 SK, 2x3.2MM | 8604120038 | 70 x 15 | 2x 3.2 | Anodised silver | 1 | 52 | H79 | 52 | ||
Corner radius 2.5 mm; with adhesive foil | ||||||||||
| ALU 40x10 R2.5 HF, 2x2.5MM | 8604126034 | 40 x 10 | 2x 2.5 | Anodised black | 1 | 140 | 9V | 140 | ||
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOG MURRPLASTIKS LABELLING SYSTEMS EN.pdf | 8 Mbytes |
|
| 8604120002 8604120002 EN_8604226004.pdf | 1011 Kbytes |
|
