8604110000 MURRPLASTIK Labelling Rectangular with radius, 1x hole Corner radius 2 mm with self-adhesive foil..
8604110000
MURRPLASTIK
121
Labelling Rectangular with radius, 1x hole Corner radius 2 mm; with self-adhesive foil Anodised silver
ALU 27x18 SI Elox R SK, 1x3,5, MS1,0
Rectangular with radius, 1x hole
Marking systems
Brand new product in its original packaging covered by the warranties and certifications provided by MURRPLASTIK
Best sellers
▲More info
▲The ALU labelling material, in mat size 300x200 mm, has been developed especially for engraving.
Coloured anodised aluminium material
Available with self-adhesive foil (SK) or with adhesive foil (HF).
Individual or prefab labels
Temperature range up to approx. 200 °C
Thickness: 1.0 mm
marking technique: Engraving
-40°C – 140°C
Aluminium anodised (ALU)
V0
| Type | Order No. | Label size mm | Number x Holes mm | Colour combination | Material thickness mm | No. per mat | Software type | MOQ qty. | ||
|---|---|---|---|---|---|---|---|---|---|---|
Corner radius 2 mm; with adhesive foil | ||||||||||
| ALU 15x15 R2 HF, 1x3.5MM | 8604116008 | 15 x 15 | 1x 3.5 | Anodised silver | 1 | 260 | 6X | 260 | ||
| ALU 27x12.5 R2 HF, 1x2.5MM | 8604116005 | 27 x 12.5 | 1x 2.5 | Anodised silver | 1 | 176 | 921 | 176 | ||
| ALU 30x55 R2 HF, 1x22.6MM | 8604116004 | 30 x 55 | 1x 22.6 | Anodised silver | 1 | 30 | 076 | 30 | ||
| ALU 30x10 R2 HF, 1.5MM | 8604116019 | 30 x 10 | 1x 5.0 | Anodised black | 1 | 200 | K70 | 200 | ||
| ALU 52X18 R2 HF, 1x2.5MM | 8604116009 | 52 x 18 | 1x 2.5 | Anodised black | 1 | 55 | A30 | 55 | ||
| ALU 30x10 R2 HF, 1x5MM | 8604116018 | 30 x 10 | 1x 5.0 | Green anodised | 1 | 200 | K69 | 200 | ||
| ALU 30x10 R2 HF, 1x5MM | 8604116017 | 30 x 10 | 1x 5.0 | Anodised Blue | 1 | 200 | K68 | 200 | ||
Corner radius 7 mm; with adhesive foil | ||||||||||
| ALU 20x20 R7 HF, 1x2.2MM | 8604116003 | 20 x 20 | 1x 2.2 | Anodised silver | 1 | 150 | 062 | 150 | ||
| ALU 20x20 R7 HF, 1x2.5MM | 8604116001 | 20 x 20 | 1x 2.5 | Anodised silver | 1 | 150 | 066 | 150 | ||
| ALU° 20x20 R7 HF, 1x2.5MM | 8604296000 | 20 x 20 | 1x 2.5 | Anodised black | 1 | 150 | 845 | 150 | ||
Corner radius 9 mm; with adhesive foil | ||||||||||
| ALU 25x25 R9 HF, 1x4.2MM | 8604116000 | 25 x 25 | 1x 4.2 | Anodised silver | 1 | 96 | 863 | 96 | ||
| ALU 25x25 R9 HF, 1x3.2MM | 8604296001 | 25 x 25 | 1x 3.2 | Anodised black | 1 | 96 | 01 | 96 | ||
| ALU 25x25 R9 HF, 1x4.5MM | 8604116006 | 25 x 25 | 1x 4.5 | Anodised black | 1 | 96 | 1G | 96 | ||
| ALU 25x25 R9 HF, 1x3.0MM | 8604116015 | 25 x 25 | 1x 3.0 | Yellow anodised | 1 | 96 | J39 | 96 | ||
| ALU 25x25 R9 HF, 1x3.0MM | 8604116014 | 25 x 25 | 1x 3.0 | Anodised red | 1 | 96 | J38 | 96 | ||
| ALU 25x25 R9 HF, 1x3.0MM | 8604116011 | 25 x 25 | 1x 3.0 | Green anodised | 1 | 96 | H27 | 96 | ||
| ALU 25x25 R9 HF, 1x3.0MM | 8604116010 | 25 x 25 | 1x 3.0 | Anodised Blue | 1 | 96 | H26 | 96 | ||
Corner radius 2 mm; with self-adhesive foil | ||||||||||
| ALU 27x18 R2 SK, 1x3.5MM | 8604110000 | 27 x 18 | 1x 3.5 | Anodised silver | 1 | 121 | 411 | 121 | ||
Corner radius 12 mm; with adhesive foil | ||||||||||
| ALU 30x30 R12 HF, 1x3.2MM | 8604116007 | 30 x 30 | 1x 3.2 | Anodised silver | 1 | 60 | 3I | 60 | ||
| ALU 20x20 R12 HF, 1x2.5MM | 8604226014 | 20 x 20 | 1x 2.5 | Anodised black | 1 | 150 | 437 | 150 | ||
Corner radius 0.5 mm; with adhesive foil | ||||||||||
| ALU 25X17,5 R0,5 HF, 1x2.8MM | 8604116016 | 25 x 17.5 | 1x 2.8 | Anodised black | 1 | 132 | J51 | 132 | ||
Corner radius 5 mm; with adhesive foil | ||||||||||
| ALU 30x10 R5 HF, 1x4.0MM | 8604116012 | 30 x 10 | 1x 4.0 | Anodised black | 1 | 200 | H75 | 200 | ||
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOG MURRPLASTIKS LABELLING SYSTEMS EN.pdf | 8 Mbytes |
|
| 8604110000 8604110000 EN_8604110000.pdf | 898 Kbytes |
|
