8604100010 MURRPLASTIK Labelling Rectangular with radius Corner radius 2 mm with self-adhesive foil Anodised..
8604100010
MURRPLASTIK
24
Labelling Rectangular with radius Corner radius 2 mm; with self-adhesive foil Anodised Blue
ALU 50x50 BL ELOX. R2 SK, MS1,0
ALU Rectangular with radius
Marking systems
Brand new product in its original packaging covered by the warranties and certifications provided by MURRPLASTIK
Best sellers
▲More info
▲The ALU labelling material, in mat size 300x200 mm, has been developed especially for engraving.
Coloured anodised aluminium material
Available with self-adhesive foil (SK) or with adhesive foil (HF).
Individual or prefab labels
Temperature range up to approx. 200 °C
Thickness: 1.0 mm
marking technique: Engraving
-40°C – 140°C
Aluminium anodised (ALU)
V0
| Type | Order No. | Label size mm | Colour combination | Material thickness mm | No. per mat | Software type | MOQ qty. | ||
|---|---|---|---|---|---|---|---|---|---|
Corner radius 2 mm; with self-adhesive foil | |||||||||
| ALU 27x86 R2 SK | 8604100003 | 27 x 86 | Anodised silver | 1 | 22 | J43 | 22 | ||
| ALU 52x18 R2 SK | 8604100007 | 52 x 18 | Anodised silver | 1 | 55 | J92 | 55 | ||
| ALU 70x26 R2 SK | 8604100004 | 70 x 26 | Anodised silver | 1 | 28 | J89 | 28 | ||
| ALU 70x42 R2 SK | 8604100006 | 70 x 42 | Anodised silver | 1 | 4 | J91 | 16 | ||
| ALU 214x70 R2 SK | 8604100008 | 214 x 70 | Anodised silver | 1 | 2 | J93 | 2 | ||
| ALU 30x200 R2 SK | 8604100002 | 30 x 200 | Anodised black | 1 | 10 | D74 | 10 | ||
| ALU 78x78 R2 SK | 8604100001 | 78 x 78 | Anodised black | 1 | 6 | D73 | 6 | ||
| ALU 50x50 R2 SK | 8604100010 | 50 x 50 | Anodised Blue | 1 | 24 | K65 | 24 | ||
| ALU 50x50 R2 SK | 8604100009 | 50 x 50 | Anodised red | 1 | 24 | K66 | 24 | ||
| ALU 50x50 R2 SK | 8604100011 | 50 x 50 | Green anodised | 1 | 24 | K67 | 24 | ||
Corner radius 2 mm; with adhesive foil | |||||||||
| ALU° 40x15 R2 HF | 8604206000 | 40 x 15 | Anodised silver | 1 | 91 | 483 | 91 | ||
| ALU° 55x20 R2 HF | 8604206001 | 55 x 20 | Anodised silver | 1 | 50 | 481 | 50 | ||
| ALU 55x95 R2 HF | 8604106005 | 55 x 95 | Anodised silver | 1 | 10 | K90 | 10 | ||
| ALU 125x40 R2 HF | 8604206003 | 125 x 40 | Anodised silver | 1 | 10 | 870 | 10 | ||
| ALU 30x65 R2 HF | 8604106001 | 30 x 65 | Anodised Blue | 1 | 30 | G63 | 30 | ||
| ALU 55x20 R2 HF | 8604106002 | 55 x 20 | Anodised red | 1 | 50 | H51 | 50 | ||
Corner radius 2.5 mm; with adhesive foil | |||||||||
| ALU 29,5x47,5 R2,5 HF | 8604106003 | 29.5 x 47.5 | Anodised black | 1 | 40 | J78 | 40 | ||
| ALU 103x20 R2,5 HF | 8604106004 | 103 x 20 | Anodised black | 1 | 20 | J77 | 20 | ||
Corner radius 2 mm; with high-strength adhesive foam foil | |||||||||
| ALU 60x100 R2 SKS | 8604102001 | 60 x 100 | Anodised black | 1 | 10 | K28 | 10 | ||
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOG MURRPLASTIKS LABELLING SYSTEMS EN.pdf | 8 Mbytes |
|
| 8604100010 8604100010 EN_8604106001.pdf | 720 Kbytes |
|
