55760 MURRELEKTRONIK CAN plug male (SUB-D) 90°
55760
MURRELEKTRONIK
CAN plug male (SUB-D) 90°
CAN-PLUG-MALE (SUB-D) 90°Screw terminals up to 1Mbits/s
Connectors with cable
Brand new product in its original packaging covered by the warranties and certifications provided by MURRELEKTRONIK
Best sellers
▲More info
▲| Art.No.: | 55760 |
| Weight: | 0.046 kg |
SUB-D9 (female), screw terminals
max. 1 Mbit/s with switchable terminal resistors
CANopen
Plastic housings with good resistance against chemicals and oils. The resistance to aggressive media should be individually tested for your application. Further details on request.
| Terminating resistor | integrated, switchable |
|---|---|
| Transfer rate | max. 1 Mbit/s with switchable terminal resistors |
| Connection cross section | max. 1 mm² |
| Protection | IP20 |
|---|---|
| Dimensions H × W × D | 65×48×16 mm |
| Temperature range | 0...+60 °C (storage temperature -25...+80 °C) |
| country of origin | DE |
|---|---|
| customs tariff number | 85366990 |
| EAN | 4048879049825 |
| eClass | 27279221 |
| Packaging unit | 1 |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOG MURRELEKTRONIK EN.pdf | 36 Mbytes |
|
| 55760 55760 55760_Data_Sheet_1.pdf | 95 Kbytes |
|
| Download general catalog |
|
