URA/T0 MICRO DETECTORS Photoelectric sensor amplification 24VDC with timer
URA/T0
MICRO DETECTORS
Photoelectric sensor amplification 24VDC with timer
URA/T0 Photoelectric sensor Amplific. 24VDC with timer
Encoders
* Brand new product in its original packaging covered by the warranties and certifications provided by MICRO DETECTORS
Best sellers
▲More info
▲Technical features
Outputs
| Switching frequency | 10Hz | |
Electrical data
| Operating Voltage | 24Vdc | |
| No-Load supply current | ≤ 100mA | |
| Max ripple content | ≤ 10% | |
| LED indicators | green (supply)red (output state)green (stability)red (alarm) | |
| Max output voltage | 250V | |
| Max output current | 3A | |
| Timer functions | yes | |
| Operating time (relè de-energized) | ≤ 40ms | |
| Reset time (relè energized) | ≤ 40ms | |
| Voltage tolerance | ± 20% | |
| Operating output | Relay NO+NC | |
| Relay with alarm output | no | |
Mechanical data
| Dimensions | 36x90x67mmù | |
| Weight | 110g | |
| Housing Material | Noryl 90 V-0 | |
| Operating temperature | -10°C … +50°C (without freeze) | |
Test/Approvals
| Approvals | CE | |
| EMC compatibility | Conforming with EMC directive according with EN60947-5-2 | |
| Degree of protection | IP20 | |
Electrical diagrams of the connections
Dimension (mm)
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE MICRODETECTORS EN.pdf | 4 Mbytes |
|
| Download general catalog |
|
